Configuration
3/07 UDC3500 Universal Digital Controller Product Manual 175
Function Prompt
Lower Display
Selections or
Range of Setting
Upper Display
Parameter
Definition
TIME 2
Same as TIME 1
TIMER 2—The timer tracks the elapsed time of the
selected event.
TIME 3
Same as TIME 1
TIMER 3—The timer tracks the elapsed time of the
selected event.
COUNT 1 COUNTER 1—The counter counts the number of
times the selected event has occurred.
DISABLE
MANUAL
DISABLE—Counter is not in use.
LOOP 1 MANUAL—Number of times Loop 1 has
been in Manual mode.
AL1SP1
AL1SP2
AL2SP1
AL2SP2
AL3SP1
AL3SP2
AL4SP1
AL4SP2
ALARM 1 SETPOINT 1—Number of times Alarm 1
Setpoint 1 has been activated.
ALARM 1 SETPOINT 2—Number of times Alarm 1
Setpoint 2 has been activated.
ALARM 2 SETPOINT 1—Number of times Alarm 2
Setpoint 1 has been activated.
ALARM 2 SETPOINT 2—Number of times Alarm 2
Setpoint 2 has been activated.
ALARM 3 SETPOINT 1—Number of times Alarm 3
Setpoint 1 has been activated.
ALARM 3 SETPOINT 2—Number of times Alarm 3
Setpoint 2 has been activated.
ALARM 4 SETPOINT 1—Number of times Alarm 4
Setpoint 1 has been activated.
ALARM 4 SETPOINT 2—Number of times Alarm 4
Setpoint 2 has been activated.
DIGIN1
DIGIN2
DIGIN3
DIGIN4
DIGITAL INPUT 1—Number of times Digital Input 1
has closed.
DIGITAL INPUT 2—Number of times Digital Input 2
has closed.
DIGITAL INPUT 3—Number of times Digital Input 3
has closed.
DIGITAL INPUT 4—Number of times Digital Input 4
has closed.
OUT1*1K
OUT2*1K
OUT3*1K
OUT4*1K
OUT5*1K
GUAR SK
PWRCYC
PVRANGE
OUTPUT 1 RELAY x 1000—Thousands of times
Output 1 relay has been activated.
OUTPUT 2 RELAY x 1000—Thousands of times
Output 2 relay has been activated.
OUTPUT 3 RELAY x 1000—Thousands of times
Output 3 relay has been activated.
OUTPUT 4 RELAY x 1000—Thousands of times
Output 4 relay has been activated.
OUTPUT 5 RELAY x 1000—Thousands of times
Output 5 relay has been activated.
GUARANTEED SOAK—Number of times unit has
been in guaranteed soak.
POWER CYCLE—Number of times unit’s power has
cycled off and on.
LOOP 1 PV RANGE—Number of times Loop 1’s PV
