Honeywell UDC3500 User Manual

Modbus Read, Write and Override Parameters plus Exception Codes
3/07 UDC3500 Universal Digital Controller Product Manual 383
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Segment #16
Soak Setpoint
Value
107 606B 24683 FP R/W Within Setpoint Limits
Segment #16
Soak Time
108 606C 24684 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak #16
122 607A 24698 FP R/W 0 to 99.9 (0 = no soak)
Segment #16
PID SET
196 60C4 24772 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #17
Ramp Time
109 606D 24685 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #17
PID SET
197 60C5 24773 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #18
Soak Setpoint
Value
110 606E 24686 FP R/W Within Setpoint Limits
Segment #18
Soak Time
111 606F 24687 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak #18
123 607B 24699 FP R/W 0 to 99.9 (0 = no soak)
Segment #18
PID SET
198 60C6 24774 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #19
Ramp Time
112 6070 24688 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #19
PID SET
199 60C7 24775 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #20
Soak Setpoint
Value
113 6071 24689 FP R/W Within Setpoint Limits
Segment #20
Soak Time
114 6072 24690 FP R/W 99.59 (0-99
Hrs:0-59 Min)
