Honeywell UDC3500 User Manual

Configuration
54 UDC3500 Universal Digital Controller Product Manual 3/07
Function Prompt
Lower Display
Selections or
Range of Setting
Upper Display
Parameter
Definition
LOCKOUT LOCKOUT applies to one of the functional groups:
Configuration, Calibration, Tuning, or Accutune.
DO NOT CONFIGURE UNTIL ALL OTHER
CONFIGURATION IS COMPLETE.
NONE
NONE—No lockout; all groups are read/write.
CALIB
CALIB—All groups are available for read/write
except for the Calibration and Keyboard Lockout
groups.
+ CONF
+ CONF—Tuning, SP Ramp, and Accutune groups
are read/write. All other groups are read only.
Calibration and Keyboard Lockout groups are not
available.
+ VIEW
+ VIEW—Tuning and Setpoint Ramp parameters are
read/write. No other parameters are viewable.
MAX
MAX—Tuning and Setpoint Ramp parameters are
available for read only. No other parameters are
viewable.
AUTO MAN
DISABLE
ENABLE
MANUAL/AUTO KEY LOCKOUT—Allows you to
disable the Manual/Auto key
DISABLE
ENABLE
ATTENTION Can only be viewed if LOCKOUT is
configured for NONE.
RUN HOLD
DISABLE
ENABLE
RUN/HOLD KEY LOCKOUT—Allows you to disable
the
Run/Hold key, for either SP Ramp or SP
Program. The Run/Hold key is never disabled when
used to acknowledge a latched alarm 1
DISABLE
ENABLE
ATTENTION Can only be viewed if LOCKOUT is
configured for NONE.
SP SEL
DISABLE
ENABLE
SETPOINT SELECT KEY LOCKOUT—Allows you
to disable the Setpoint Select key
DISABLE
ENABLE
ATTENTION Can only be viewed if LOCKOUT is
configured for NONE.
