Manual 271
If you enter incorrect values, press the CANCEL key at any time. After motion has begun, press
STOP on the front panel to bring the machine smoothly to a stop before the programmed motion is
complete.
Rip Cut mode is useful for making a cut along a specified linear path. Motion stops and cutting action
ceases either when the new position is reached or when the STOP key is pressed. If an exact
distance is not known, enter a distance longer than needed in the right direction, and then press
STOP to abort the cut.
Manual Options
Pressing the Manual Options soft key accesses the Manual Options screen.
Home Axes
Pressing the Manual Options soft key accesses the Homes Axes screen.
View Sheet/View Part
View Sheet allows the viewing of a part as it would appear on the plate. After pressing the View Sheet
soft key, the display window zooms out to show the part in relationship to the entire plate.
