Password Setups 346
Reset
The Reset Softkey may be used to reset or clear all Station setup parameters setting the values to
“None”.
Part Program Support
The following program codes are used to enable a station for use. Station Select and Process Select
codes should be placed prior to the cut / mark.
Station Selects
Stations (Lifter / THCs) may be selected / de-selected using an EIA-274D program code with the
following format.
Code Description
M19 Tvalue Cancel All Station Selections
M37 Tvalue Select Station 1-20 (Tvalue)
M38 Tvalue De-Select Station 1-20 (Tvalue)
Additionally, these Station Select program codes may be overridden using the user selected THC
inputs to the control. The feature to override the part program must be enabled at the Cutting Setup
Screen.
Process Selects
Process Selections may be selected using an EIA-274D program code with the following format.
Example: M36 Tvalue
Misc. M Code
Valve Identity
T1 = Plasma Process 1
T2 = Plasma Process 2
T3 = Marker Process 1
T4 = Marker Process 2
T5 = Laser Process
Station Configuration Variables
The following options are available for the station configuration
Lifter
None
Sensor THC
Command THC (w/ Serial Link)
HD4070 Integrated THC 1 or 2 (used only with the HD4070
®
power supply)
Other (any stand alone Lifter Station)
Power Supplies
None HD4070 Torch 1or 2 Powermax series
Max100/ 100D HT4001 FineLine 100
Max200 HT4100 FineLine 200
HT2000 HT4400 Other (any other Plasma system)
HD3070 HPR130
