Edge Ti™ 514

Torch Mounting Block Kit

Mount the torch mounting block kit to the lifter torch breakaway assembly. See below.

The mounting blocks are available in three sizes as listed.

 PN = MECO-0108 Torch Mounting Block 1 3/4” diameter

 PN = MECO-0109 Torch Mounting Block 2” diameter

 PN = MECO-0130 Torch Mounting Block 1 3/8” diameter

Breakaway

Mounting Plate

Torch Breakaway

Torch Mounting Clamp
