Serial Ports 476

RS- 232 / 422 Configuration

The jumpers on J9 and J10 would be placed in position for RS-232 or RS-422 for operation on the

appropriate port. Selection may very slightly depending on control type.

Serial Isolation card ( selected models)

BMD

AMD

BTR

ATR

RS-422

AHST

BHST

RS-232

J10
