Intel Cyclone 10 GX User Manual

Figure 43. 10GBASE-R PHY as Part of the IEEE802.3-2008 Open System Interconnection
(OSI)
Application
Presentation
Session
Transport
Network
Data Link
Physical
OSI Reference
Model Layers
Higher Layers
LAN
CSMA/CD
LAYERS
Logical Link Control (LLC) or other MAC Client
MAC Control (Optional)
Media Access Control (MAC)
Reconciliation
XGMII
10GBASE-R PCS
MDI
10GBASE-R
PHY
Medium
10GBASE-R
(PCS, PMA, PMD)
PMA
PMD
To 10GBASE-R PHY
(Point-to-Point Link)
MDI: Medium Dependent Interface
PCS: Physical Coding Sublayer
PHY: Physical Layer Device
PMA: Physical Medium Attachment
PMD: Physical Medium Dependent
XGMII: 10 GB Media Independent Interface
Legend
10GBASE-R is a single-channel protocol that runs independently. You can configure
the transceivers to implement 10GBASE-R PHY functionality by using the presets of
the Native PHY IP. The complete PCS and PHY solutions can be used to interface with a
third-party PHY MAC layer as well.
The following 10GBASE-R variants area available from presets:
• 10GBASE-R
• 10GBASE-R Low Latency
• 10GBASE-R Register Mode
Intel recommends that you use the presets for selecting the suitable 10GBASE-R
variants directly if you are configuring through the Native PHY IP core.
2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
UG-20070 | 2018.09.24
Send Feedback
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
99
