3. PLLs and Clock Networks
This chapter describes the transceiver phase locked loops (PLLs), internal clocking
architecture, and the clocking options for the transceiver and the FPGA fabric
interface.
As shown in the following figure, transceiver banks can have either four or six
transceiver channels. For every three channels, you get one advanced transmit (ATX)
PLL, one fractional PLL (fPLL), and one Master clock generation block (CGB). Refer to
the Device Transceiver Layout section to identify which devices have three channel
transceiver banks.
The Cyclone 10 GX transceiver clocking architecture supports both bonded and non-
bonded transceiver channel configurations. Channel bonding is used to minimize the
clock skew between multiple transceiver channels. For Cyclone 10 GX transceivers, the
term bonding can refer to PMA bonding as well as PMA and PCS bonding. Refer to the
Channel Bonding section for more details.
