Intel Cyclone 10 GX User Manual

8.7.5. XCVR_C10_TX_PRE_EMP_SWITCHING_CTRL_PRE_TAP_1T
Pin planner or Assignment Editor Name
Transmitter Pre-Emphasis First Pre-Tap Magnitude
Description
Controls the magnitude of the first pre-tap for pre-emphasis. The default value is 0.
Table 231. Available Options
Value Description
0 – 16 Magnitude 0 – 16
Note: Refer to Cyclone 10 GX Pre-Emphasis and Output Swing Settings spreadsheet for
selecting legal pre-emphasis and differential output voltage settings.
Assign To
TX serial data pin.
Syntax
set_instance_assignment -name
XCVR_C10_TX_PRE_EMP_SWITCHING_CTRL_PRE_TAP_1T <value> -to
<tx_serial_data pin name>
Related Information
Cyclone 10 GX Pre-Emphasis and Output Swing Settings
8.7.6. XCVR_C10_TX_PRE_EMP_SWITCHING_CTRL_PRE_TAP_2T
Pin planner or Assignment Editor Name
Transmitter Pre-Emphasis Second Pre-Tap Magnitude
Description
Controls the magnitude of the second pre-tap for pre-emphasis. The default value is
0.
Table 232. Available Options
Value Description
0 – 7 Magnitude 0 – 7
Note: Refer to Cyclone 10 GX Pre-Emphasis and Output Swing Settings spreadsheet for
selecting legal pre-emphasis and differential output voltage settings.
Assign To
TX serial data pin.
8. Analog Parameter Settings
UG-20070 | 2018.09.24
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
Send Feedback
398
