Table 127. Bit Mappings When the Simplified Interface Is Disabled
This section contains the recommended settings for this protocol. Refer to Using the Cyclone 10 GX Transceiver
Native PHY IP Core for the full range of parameter values.
Signal Name Gen1 (TX Byte Serializer and
RX Byte Deserializer disabled)
Gen1 (TX Byte Serializer and RX Byte
Deserializer in X2 mode), Gen2 (TX
Byte Serializer and RX Byte
Deserializer in X2 mode)
tx_parallel_data tx_parallel_data[7:0] tx_parallel_data[29:22,7:0]
tx_datak tx_parallel_data[8] tx_parallel_data[30,8]
pipe_tx_compliance tx_parallel_data[9] tx_parallel_data[31,9]
pipe_tx_elecidle tx_parallel_data[10] tx_parallel_data[32,10]
pipe_tx_detectrx_loopbacK tx_parallel_data[46] tx_parallel_data[46]
pipe_powerdown tx_parallel_data[48:47] tx_parallel_data[48:47]
pipe_tx_margin tx_parallel_data[51:49] tx_parallel_data[51:49]
pipe_tx_swing tx_parallel_data[53] tx_parallel_data[53]
rx_parallel_data rx_parallel_data[7:0] rx_parallel_data[39:32,7:0]
rx_datak rx_parallel_data[8] rx_parallel_data[40,8]
rx_syncstatus rx_parallel_data[10] rx_parallel_data[42,10]
pipe_phy_status rx_parallel_data[65] rx_parallel_data[65]
pipe_rx_valid rx_parallel_data[66] rx_parallel_data[66]
pipe_rx_status rx_parallel_data[69:67] rx_parallel_data[69:67]
pipe_tx_deemph
N/A
tx_parallel_data[52]
Refer to section 6.6 of Intel PHY Interface for PCI Express (PIPE) Architecture for more
information.
Related Information
• Intel PHY Interface for PCI Express (PIPE) Architecture
• Bit Mappings When the Simplified Interface is Disabled on page 143
• Using the Cyclone 10 GX Transceiver Native PHY IP Core on page 26
2.7.9. fPLL Ports for PIPE
Table 128. fPLL Ports for PIPE
This section contains the recommended settings for this protocol. Refer to Using the Cyclone 10 GX Transceiver
Native PHY IP Core for the full range of parameter settings.
Port
Direction Clock Domain Description
Pll_powerdown
Input Asynchronous Resets the PLL when asserted high. Needs to be connected to
the Transceiver PHY Reset Controller pll_powerdown output.
Pll_reflck0
Input N/A Reference clock input port 0. There are five reference clock
input ports. The number of reference clock ports available
depends on the Number of PLL reference clocks parameter.
continued...
2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
UG-20070 | 2018.09.24
Send Feedback
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
143
