Port Direction Clock Domain Description
tx_serial_clk
Output N/A High speed serial clock output port for GX channels.
Represents the x1 clock network.
For Gen1x1, Gen2x1, connect the output from this port to the
tx_serial_clk[5:0] input of the native PHY IP.
For Gen1x2, x4 use the tx_bonding_clocks[5:0] output
port to connect to the Native PHY IP.
For Gen2x2, x4 use the tx_bonding_clocks output port to
connect to the Native PHY IP.
pll_locked
Output Asynchronous Active high status signal which indicates if PLL is locked.
pll_pcie_clk
Output N/A This is the hclk required for PIPE interface.
For Gen1x1, x2, x4 use this port to drive the
pipe_hclk_infor the PIPE interface.
For Gen2x1, x2, x4 use this port to drive the pipe_hclk_in
for the PIPE interface.
Pll_cal_busy
Output Asynchronous Status signal which is asserted high when PLL calibration is in
progress.
If this port is not enabled in Transceiver PHY Reset Controller,
then perform logical OR with this signal and the tx_cal_busy
output signal from Native PHY to input the tx_cal_busy on
the reset controller IP.
Mcgb_rst
Input Asynchronous Master CGB reset control.
tx_bonding_clocks[5:0]]
Output N/A Optional 6-bit bus which carries the low speed parallel clock
outputs from the Master CGB. It is used for channel bonding,
and represents the x6/xN clock network.
For Gen1x1, this port is disabled.
For Gen1x2, x4 connect the output from this port to the
tx_bonding_clocks input on Native PHY.
For Gen2x1, this port is disabled.
For Gen2x2, x4 connect the output from this port to the
tx_bonding_clocks input on Native PHY.
pcie_sw[1:0]
Input Asynchronous 2-bit rate switch control input used for PCIe protocol
implementation.
For Gen1, this port is N/A
For Gen 2x2, x4 connect the pipe_sw output from Native PHY
to this port.
pcie_sw_done[1:0]
Output Asynchronous 2-bit rate switch status output used for PCIe protocol
implementation.
For Gen1, this port is N/A.
For Gen 2x2, x4 connect the pcie_sw_done[1:0] output
from fPLL to the pipe_sw_done input of Native PHY .
Related Information
Using the Cyclone 10 GX Transceiver Native PHY IP Core on page 26
2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
UG-20070 | 2018.09.24
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
Send Feedback
144
