calibration is done. If you write 0x2 to 0x0 during calibration, PreSICE can stop the
calibration process and return the internal configuration bus back to you; therefore,
calibration is not done while the reconfig_waitrequest is low. The PMA
tx_cal_busy and rx_cal_busy are from the same internal node which cannot be
separated from the hardware. Configure the capability register 0x281[5:4] to enable
or disable tx_cal_busy or rx_cal_busy individually through the Avalon-MM
reconfiguration interface.
Related Information
• Arbitration on page 325
• Avalon Interface Specifications
• Reconfiguration Interface and Dynamic Reconfiguration Chapter on page 315
7.2. Calibration Registers
The Cyclone 10 GX transceiver PMA and PLLs include the following types of registers
for calibration:
• Avalon-MM interface arbitration registers
• Calibration enable registers
• Capability registers
• Rate switch flag registers
The Avalon-MM interface arbitration registers enable you to request internal
configuration bus access.
The PMA and PLL calibration enable registers for user recalibration are mapped to
offset address 0x100. All calibration enable registers are self-cleared after the
calibration process is completed.
The tx_cal_busy, rx_cal_busy, ATX PLL pll_cal_busy, and fPLL
pll_cal_busy signals are available from the capability registers.
The rate switch flag registers are only used for CDR rate change.
7.2.1. Avalon-MM Interface Arbitration Registers
Table 206. Avalon-MM Interface Arbitration Registers
Bit Offset Address Description
[0] 0x0
(32)
This bit arbitrates the control of Avalon-MM interface.
• Set this bit to 0 to request control of the internal configuration
bus by user.
• Set this bit to 1 to pass the internal configuration bus control to
PreSICE.
[1] 0x0 This bit indicates whether or not calibration is done. This is the
inverted cal_busy signal. You can write to this bit; however, if
you accidentally write 0x0 without enabling any calibration bit in
continued...
(32)
The transceiver channel, ATX PLL, and fPLL use the same offset address.
7. Calibration
UG-20070 | 2018.09.24
Send Feedback
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
375
