Name Direction Clock Domain Description
receive circuitry receives all words in the reverse order. The
bit reversal circuitry operates on the output of the word
aligner.
tx_polinv[<n>-1:0]
Input Asynchronous When asserted, the TX polarity bit is inverted. Only active
when TX bit polarity inversion is enabled.
rx_polinv[<n>-1:0]
Input Asynchronous When asserted, the RX polarity bit is inverted. Only active
when RX bit polarity inversion is enabled.
rx_std_signaldetect[<n
>-1:0]
Output Asynchronous When enabled, the signal threshold detection circuitry
senses whether the signal level present at the RX input
buffer is above the signal detect threshold voltage. You can
specify the signal detect threshold using a Quartus Prime
Settings File (.qsf) assignment. This signal is required for
the PCI Express, SATA and SAS protocols.
2.4.11. IP Core File Locations
When you generate your Transceiver Native PHY IP, the Quartus
®
Prime software
generates the HDL files that define your instance of the IP. In addition, the Quartus
Prime software generates an example Tcl script to compile and simulate your design in
the ModelSim simulator. It also generates simulation scripts for Synopsys VCS, Aldec
Active-HDL, Aldec Riviera-Pro, and Cadence Incisive Enterprise.
2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
UG-20070 | 2018.09.24
Send Feedback
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
67
