6.15.1. Altera Debug Master Endpoint
The ADME is a JTAG-based Avalon Memory-Mapped (Avalon-MM) master that provides
access to the transceiver and PLL registers through the system console. You can
enable ADME using the Enable Altera Debug Master Endpoint option available
under the Dynamic Reconfiguration tab in the Native PHY and PLL IP cores. When
using ADME, the Quartus Prime software inserts the debug interconnect fabric to
connect with USB, JTAG, or other net hosts. Select the Share Reconfiguration
Interface parameter when the Native PHY IP instance has more than one channel.
When you enable ADME in your design, you must
• connect an Avalon-MM master to the reconfiguration interface.
•
OR connect the, reconfig_reset signals and ground the reconfig_write,
reconfig_read, reconfig_address and reconfig_write data signals of the
reconfiguration interface. If the reconfiguration interface signals are not connected
appropriately, there will be no clock or reset for the ADME and ADME will not
function as expected.
6.15.2. Optional Reconfiguration Logic
The Cyclone 10 GX Transceiver Native PHY, ATX PLL, fPLL, and CMU PLL IP cores
contain soft logic for debug purposes known as the Optional Reconfiguration Logic.
This soft logic provides a set of registers that enable you to determine the state of the
Native PHY and PLL IP cores.
You can enable the following optional reconfiguration logic options in the transceiver
Native PHY and PLL IP cores:
• Capability registers
• Control and status registers
• PRBS soft accumulators (Native PHY IP core only)
6.15.2.1. Capability Registers
The capability registers provide high level information about the transceiver channel
and PLL configuration.
The capability registers capture a set of chosen capabilities of the PHY that cannot be
reconfigured. The following capability registers are available for the Native PHY IP
core.
Table 195. Capability Registers for the Native PHY IP Core
Address Type Name Description
0x200[7:0] RO IP Identifier Unique identifier for the Native PHY IP instance.
0x204[0] RO Status Register Enabled Indicates whether the status registers have been
enabled. 1'b1 indicates that the status registers are
enabled.
0x205[0] RO Control Register Enabled Indicates whether the control registers have been
enabled. 1'b1 indicates that the control registers are
enabled.
0x210[7:0] RO Number of Channels Shows the number of channels specified for the
Native PHY IP instance.
continued...
