Intel Cyclone 10 GX

Related Information
• Transceiver Channel Calibration Registers on page 376
For more details about PMA recalibration
• Rate Switch Flag Register on page 379
• PMA Capability Registers for Calibration Status on page 378
7.6. Calibration Revision History
Document
Version
Changes
2017.11.06 Made the following change:
• Added a note "CDR/CMU PLL calibration is part of PMA RX calibration".
• Updated the flow of "User Recalibration" topic.
• For the Transceiver Channel PMA Calibration Registers table: Changed bit[6] from Reserved to
Adaptation mode. Set 0, to disable adaptation mode.
• Clarified the User Recalibration section.
• Clarified the PMA Recalibration section.
2017.05.08 Initial release.
