Intel Cyclone 10 GX

Syntax
set_instance_assignment -name
XCVR_C10_TX_PRE_EMP_SWITCHING_CTRL_PRE_TAP_2T <value> -to
<tx_serial_data pin name>
Related Information
Cyclone 10 GX Pre-Emphasis and Output Swing Settings
8.7.7. XCVR_C10_TX_PRE_EMP_SWITCHING_CTRL_1ST_POST_TAP
Pin planner or Assignment Editor Name
Transmitter Pre-Emphasis First Post-Tap Magnitude
Description
Controls the magnitude of the first post-tap for pre-emphasis. The default value is 0.
Table 233. Available Options
Value Description
0 –25 Magnitude 0 –25
Note: Refer to Cyclone 10 GX Pre-Emphasis and Output Swing Settings spreadsheet for
selecting legal pre-emphasis and differential output voltage settings.
Assign To
TX serial data pin.
Syntax
set_instance_assignment -name
XCVR_C10_TX_PRE_EMP_SWITCHING_CTRL_1ST_POST_TAP <value> -to
<tx_serial_data pin name>
Related Information
Cyclone 10 GX Pre-Emphasis and Output Swing Settings
8.7.8. XCVR_C10_TX_PRE_EMP_SWITCHING_CTRL_2ND_POST_TAP
Pin planner or Assignment Editor Name
Transmitter Pre-Emphasis Second Post-Tap Magnitude
Description
Controls the magnitude of the second post-tap for pre-emphasis. The default value is
0.
