2.4.8. PMA Ports
This section describes the PMA and calibration ports for the Cyclone 10 GX Transceiver
Native PHY IP core.
The following tables, the variables represent these parameters:
• <n>—The number of lanes
• <d>—The serialization factor
• <s>—The symbol size
• <p>—The number of PLLs
Table 39. TX PMA Ports
Name Direction Clock Domain Description
tx_serial_data[<n>
-1:0]
Input N/A This is the serial data output of the TX PMA.
tx_serial_clk0
Input Clock This is the serial clock from the TX PLL. The frequency of this
clock depends on the data rate and clock division factor. This
clock is for non bonded channels only. For bonded channels
use the tx_bonding_clocks clock TX input.
tx_bonding_clocks[
<n><6>-1:0]
Input Clock This is a 6-bit bus which carries the low speed parallel clock
per channel. These clocks are outputs from the master CGB.
Use these clocks for bonded channels only.
Optional Ports
tx_serial_clk1
tx_serial_clk2
tx_serial_clk3
tx_serial_clk4
Inputs Clocks These are the serial clocks from the TX PLL. The frequency of
these clocks depends on the data rate and clock division
factor. These additional ports are enabled when you specify
more than one TX PLL.
tx_analog_reset_ac
k
Output Asynchronous
Enables the optional tx_pma_analog_reset_ack output.
This port should not be used for register mode data transfers
tx_pma_clkout
Output Clock This clock is the low speed parallel clock from the TX PMA. It
is available when you turn on Enable tx_pma_clkout port
in the Transceiver Native PHY IP core Parameter Editor.
(19)
tx_pma_div_clkout
Output Clock
If you specify a tx_pma_div_clkout division factor of 1 or
2, this clock output is derived from the PMA parallel clock
(low speed parallel clock). If you specify a
tx_pma_div_clkout division factor of 33, 40, or 66, this
clock is derived from the PMA serial clock. This clock is
commonly used when the interface to the TX FIFO runs at a
different rate than the PMA parallel clock frequency, such as
66:40 applications.
continued...
(19)
This clock is not to be used to clock the FPGA - transceiver interface. This clock may be used
as a reference clock to an external clock cleaner.
2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
UG-20070 | 2018.09.24
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
Send Feedback
50
