Intel Cyclone 10 GX User Manual

The following table describes the addresses and bits for switching CDR and CMU
reference clock inputs. The number of exposed rx_cdr_refclk (CDR) or
pll_refclk (CMU) varies according to the number of reference clocks you specify.
Use the CMU reconfiguration interface for switching the CMU reference clock.
Table 182. Register Map for Switching CDR Reference Clock Inputs
Native PHY Port Description Address Bits
cdr_refclk0 Represents logical refclk0.
Lookup register x16A[7:0]
stores the mapping from logical
refclk0 to the physical refclk.
0x16A (Lookup Register) [7:0]
cdr_refclk1 Represents logical refclk1.
Lookup register x16B[7:0]
stores the mapping from logical
refclk1 to the physical refclk.
0x16B (Lookup Register) [7:0]
cdr_refclk2 Represents logical refclk2.
Lookup register x16C[7:0]
stores the mapping from logical
refclk2 to the physical refclk.
0x16C (Lookup Register) [7:0]
cdr_refclk3 Represents logical refclk3.
Lookup register x16D[7:0]
stores the mapping from logical
refclk3 to the physical refclk.
0x16D (Lookup Register) [7:0]
cdr_refclk4 Represents logical refclk4.
Lookup register x16E[7:0]
stores the mapping from logical
refclk4 to the physical refclk.
0x16E (Lookup Register) [7:0]
N/A CDR refclk selection MUX. 0x141 [7:0]
When performing a reference clock switch, note the logical reference clock to switch to
and the respective address and bits. After determining the logical reference clock,
follow this procedure to switch to the selected CDR reference clock:
1. Perform the necessary steps from steps 1 to 7 in Steps to Perform Dynamic
Reconfiguration.
2. Read from the lookup register and save the required 8-bit pattern. For example,
switching to logical refclk3 requires saving bits[7:0] at address 0x16D.
3.
Perform a read-modify-write to bits [7:0] at address 0x141 using the 8-bit value
obtained from the lookup register.
4. Perform the necessary steps from steps 9 to 12 in Steps to Perform Dynamic
Reconfiguration.
Related Information
Steps to Perform Dynamic Reconfiguration on page 328
6.12. Changing PMA Analog Parameters
You can use the reconfiguration interface on the Transceiver Native PHY IP core to
change the value of PMA analog features.
6. Reconfiguration Interface and Dynamic Reconfiguration
UG-20070 | 2018.09.24
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
Send Feedback
338
