Figure 35: MX960 with High-Capacity Second-Generation AC Power Supplies Installed
g100750
1
3
4
655
2
4—1— Power supply ejectorsAir exhuast
5—2— Grounding pointsPower distribution unit cover
6—3— ESDPower supplies
The minimum number of power supplies must be present in the router at all times. Refer to
Table 63 on page 133.
Table 63: Minimum Number of Power Supplies Required for the MX960
Model NumberMinimum Required Number of
Power Supplies
ConfigurationRouter Model
MX960-5K-ACOne per zone x two zones = 2 power
supplies
High-capacity
second-generation AC
MX960
PWR-MX960-4100-ACOne per zone x two zones = 2 power
supplies
High-capacity ACMX960
PWR-MX960-AC2Normal-capacity ACMX960
133
