Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1175
15 Parameter reference
15.7 Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00023 Imax in generator mode Linear value 24552 5FE8 E 1 INTEGER_16 100
C00024
LS_DriveInterface: bNActCompare Linear value 24551 5FE7 E 1 INTEGER_16 100
C00025
LS_DriveInterface: bNActHysterese Linear value 24550 5FE6 A 1 INTEGER_16 100
C00026
AINx: Offset Linear value 24549 5FE5 A 2 INTEGER_16 100
C00027
AINx: Gain Linear value 24548 5FE4 A 2 INTEGER_32 10000
C00028
AINx: Input voltage Linear value 24547 5FE3 A 2 INTEGER_16 100
C00029 AINx: Input current Linear value 24546 5FE2 A 2 INTEGER_16 100
C00033 AINx: Output value Linear value 24542 5FDE A 2 INTEGER_16 100
C00034 AINx: Configuration Selection list 24541 5FDD A 2 UNSIGNED_8 1
C00036
DC braking: Current Linear value 24539 5FDB E 1 INTEGER_16 100
C00039
Fixed setpoint x (L_NSet_1 n-Fix) Linear value 24536 5FD8 A 15 INTEGER_16 100
C00050
MCTRL: Speed setpoint Linear value 24525 5FCD E 1 INTEGER_32 1
C00051 MCTRL: Actual speed value Linear value 24524 5FCC E 1 INTEGER_32 1
C00052 Motor voltage Linear value 24523 5FCB E 1 UNSIGNED_16 1
C00053 DC-bus voltage Linear value 24522 5FCA E 1 UNSIGNED_16 1
C00054 Motor current Linear value 24521 5FC9 E 1 UNSIGNED_16 100
C00055 Actual values Linear value 24520 5FC8 A 2 INTEGER_16 1
C00056 Torque Linear value 24519 5FC7 A 2 INTEGER_32 100
C00057 Maximum torque Linear value 24518 5FC6 E 1 UNSIGNED_32 100
C00058 Output frequency Linear value 24517 5FC5 E 1 INTEGER_32 100
C00059 Appl.: Reference frequency C11 Linear value 24516 5FC4 E 1 UNSIGNED_32 100
C00061 Heatsink temperature Linear value 24514 5FC2 E 1 INTEGER_16 1
C00062 Interior temperature Linear value 24513 5FC1 A 1 INTEGER_16 1
C00064 Device utilisation (Ixt) Linear value 24511 5FBF A 3 INTEGER_16 100
C00065 Supply voltage 24V Linear value 24510 5FBE E 1 INTEGER_16 10
C00066 Thermal motor load (I²xt) Linear value 24509 5FBD E 1 INTEGER_16 100
C00070 Vp speed controller Linear value 24505 5FB9 A 3 UNSIGNED_16 100
C00071
Ti speed controller Linear value 24504 5FB8 A 3 UNSIGNED_16 10
C00072
SC: Tdn speed controller Linear value 24503 5FB7 E 1 UNSIGNED_16 100
C00073
Imax/M controller gain Linear value 24502 5FB6 A 2 UNSIGNED_16 100
C00074
Reset time Imax/M controller Linear value 24501 5FB5 A 2 UNSIGNED_16 1
C00075
Vp current controller Linear value 24500 5FB4 E 1 UNSIGNED_16 100
C00076
Ti current controller Linear value 24499 5FB3 E 1 UNSIGNED_16 100
C00077
SC: Vp field controller Linear value 24498 5FB2 E 1 UNSIGNED_16 100
C00078
SC: Tn field controller Linear value 24497 5FB1 E 1 UNSIGNED_16 10
C00079
SC: Settings Selection list 24496 5FB0 A 4 UNSIGNED_8 1
C00080
Override point of field weakening Linear value 24495 5FAF E 1 INTEGER_16 1
C00081
Rated motor power Linear value 24494 5FAE E 1 UNSIGNED_16 100
C00082
Motor rotor resistance Linear value 24493 5FAD E 1 UNSIGNED_32 1
C00083
Motor rotor time constant Linear value 24492 5FAC E 1 UNSIGNED_16 1
C00084 Motor stator resistance Linear value 24491 5FAB E 1 UNSIGNED_32 1
C00085
Motor stator leakage inductance Linear value 24490 5FAA E 1 UNSIGNED_16 100
C00087
Rated motor speed Linear value 24488 5FA8 E 1 UNSIGNED_16 1
C00088
Rated motor current Linear value 24487 5FA7 E 1 UNSIGNED_16 100
C00089
Rated motor frequency Linear value 24486 5FA6 E 1 UNSIGNED_16 1
C00090
Rated motor voltage Linear value 24485 5FA5 E 1 UNSIGNED_16 1
C00091
Motor cosine phi Linear value 24484 5FA4 E 1 UNSIGNED_8 100
C00092
Motor magnetising inductance Linear value 24483 5FA3 E 1 UNSIGNED_16 10
C00093
Power section ID Linear value 24482 5FA2 E 1 UNSIGNED_16 1
C00095 Motor magnetising current Linear value 24480 5FA0 E 1 UNSIGNED_16 100
Code Name Type Index Data
dec hex DS DA Data type Factor CINH
Greyed out = display parameter (read only access)
