15 Parameter reference
15.7 Table of attributes
1176
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00097 Rated motor torque Linear value 24478 5F9E E 1 UNSIGNED_32 100
C00098 Rated device current Linear value 24477 5F9D E 1 UNSIGNED_16 10
C00099 Firmware version String 24476 5F9C E 1 VISIBLE_STRING [12]
C00100 Firmware version Linear value 24475 5F9B A 4 UNSIGNED_8 1
C00101 Add. acceleration time x Linear value 24474 5F9A A 15 UNSIGNED_32 1000
C00103
Add. deceleration time x Linear value 24472 5F98 A 15 UNSIGNED_32 1000
C00104
Quick stop setting Bit coded 24471 5F97 A 1 UNSIGNED_16 1
C00105
Decel. time - quick stop Linear value 24470 5F96 E 1 UNSIGNED_32 1000
C00106
Auto-DCB: Hold time Linear value 24469 5F95 E 1 UNSIGNED_32 1000
C00107
DC braking: Hold time Linear value 24468 5F94 E 1 UNSIGNED_32 1000
C00114
DigInX: Inversion Bit coded 24461 5F8D E 1 UNSIGNED_16 1
C00115
DI 1/2 & 6/7: Function Selection list 24460 5F8C A 2 UNSIGNED_8 1
C00117
Status of brake output BD Selection list 24458 5F8A E 1 UNSIGNED_8 1
C00118 DigOutX: Inversion Bit coded 24457 5F89 E 1 UNSIGNED_8 1
C00120
Setting of motor overload (I²xt) Linear value 24455 5F87 E 1 INTEGER_16 100
C00122
Initial value motor overload (I²xt) Linear value 24453 5F85 A 1 UNSIGNED_16 100
C00123
Device utilisat. threshold (Ixt) Linear value 24452 5F84 E 1 INTEGER_16 100
C00124
Current monitoring: Breaking current Linear value 24451 5F83 A 1 UNSIGNED_16 100
C00129
Brake resistance value Linear value 24446 5F7E E 1 UNSIGNED_16 10
C00130
Rated brake resistor power Linear value 24445 5F7D E 1 UNSIGNED_16 1
C00131
Rated heat amount of brake resist. Linear value 24444 5F7C E 1 UNSIGNED_16 10
C00133
Brake resistor utilisation Linear value 24442 5F7A E 1 UNSIGNED_16 1
C00134 L_NSet_1: Ramp smoothing Selection list 24441 5F79 E 1 UNSIGNED_8 1
C00136
Communication control words Bit coded 24439 5F77 A 2 UNSIGNED_16 1
C00137 Device status Selection list 24438 5F76 E 1 UNSIGNED_16 1
C00138 Internal control signals Bit coded 24437 5F75 A 3 UNSIGNED_16 1
C00142 Auto-start option Bit coded 24433 5F71 E 1 UNSIGNED_8 1
C00144
Thermal switching frequency reduction Selection list 24431 5F6F E 1 UNSIGNED_8 1
C00148
LS_DriveInterface: Error message config. Bit coded 24427 5F6B E 1 UNSIGNED_16 1
C00150
Status word Bit coded 24425 5F69 E 1 UNSIGNED_16 1
C00155 Extended status word Bit coded 24420 5F64 E 1 UNSIGNED_16 1
C00158 Cause of controller inhibit Bit coded 24417 5F61 E 1 UNSIGNED_16 1
C00159 Cause of quick stop QSP Bit coded 24416 5F60 E 1 UNSIGNED_16 1
C00160 Status determining error (16-bit) Linear value 24415 5F5F A 1 UNSIGNED_16 1
C00161 LS_SetError_x: Error number Linear value 24414 5F5E A 8 UNSIGNED_16 1
C00162
Error number masked Linear value 24413 5F5D A 1 UNSIGNED_32 1
C00163 Logbook - binary elements Selection list 24412 5F5C A 2 UNSIGNED_16 1
C00164
Logbook - analog elements Selection list 24411 5F5B A 1 UNSIGNED_16 1
C00165
Error information String 24410 5F5A A 2 VISIBLE_STRING [14]
C00166 Error information text String 24409 5F59 A 6 VISIBLE_STRING [31]
C00168 Status determining error Linear value 24407 5F57 E 1 UNSIGNED_32 1
C00169 Logbook setting Bit coded 24406 5F56 E 1 UNSIGNED_16 1
C00170
Current error Linear value 24405 5F55 E 1 UNSIGNED_32 1
C00173 Mains voltage Selection list 24402 5F52 E 1 UNSIGNED_8 1 CINH
C00174
Reduced brake chopper threshold Linear value 24401 5F51 E 1 UNSIGNED_8 1
C00175
Brake energy management Selection list 24400 5F50 E 1 UNSIGNED_8 1 CINH
C00177
Switching cycles Linear value 24398 5F4E A 9 UNSIGNED_32 1
C00178 Elapsed-hour meter Linear value 24397 5F4D E 1 UNSIGNED_32 1
C00179 Power-on time meter Linear value 24396 5F4C E 1 UNSIGNED_32 1
C00180 Running time Linear value 24395 5F4B A 3 UNSIGNED_32 1
Code Name Type Index Data
dec hex DS DA Data type Factor CINH
Greyed out = display parameter (read only access)
