Lenze 8400 - Page 1177

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1177
15 Parameter reference
15.7 Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00181 Time settings Linear value 24394 5F4A A 1 UNSIGNED_16 1
C00182
L_NSet_1: S-ramp time PT1 Linear value 24393 5F49 E 1 INTEGER_16 100
C00184
AutoFailReset repetition time Linear value 24391 5F47 E 1 UNSIGNED_16 1
C00185
AutoFailReset residual runtime Linear value 24390 5F46 E 1 UNSIGNED_16 1
C00186 Max. number of AutoFailReset processes Linear value 24389 5F45 E 1 UNSIGNED_8 1
C00187
Current AutoFailReset processes Linear value 24388 5F44 E 1 UNSIGNED_8 1
C00188 AutoFailReset configuration Selection list 24387 5F43 E 1 UNSIGNED_8 1
C00189
Resp. to too frequent AutoFailReset Selection list 24386 5F42 E 1 UNSIGNED_8 1
C00190
L_NSet_1: Setpoint arithmetic Selection list 24385 5F41 E 1 UNSIGNED_8 1
C00191
Logbook access index User Linear value 24384 5F40 A 1 UNSIGNED_8 1
C00192
Logbook data User String 24383 5F3F A 1 OCTET_STRING [32]
C00193 Logbook element User Linear value 24382 5F3E A 6 UNSIGNED_32 1
C00199 Description data String 24376 5F38 A 5 VISIBLE_STRING [32]
C00200
Firmware product type String 24375 5F37 E 1 VISIBLE_STRING [19]
C00201 Firmware String 24374 5F36 A 6 VISIBLE_STRING [22]
C00203 Product type code String 24372 5F34 A 9 VISIBLE_STRING [24]
C00204 Serial number String 24371 5F33 A 9 VISIBLE_STRING [24]
C00219 Identification Linear value 24356 5F24 A 4 UNSIGNED_32 1
C00220 L_NSet_1: Acceleration time - add.
setpoint
Linear value 24355 5F23 E 1 UNSIGNED_32 1000
C00221
L_NSet_1: Deceleration time - add.
setpoint
Linear value 24354 5F22 E 1 UNSIGNED_32 1000
C00222
L_PCTRL_1: Vp Linear value 24353 5F21 E 1 INTEGER_16 10
C00223
L_PCTRL_1: Tn Linear value 24352 5F20 E 1 UNSIGNED_16 1
C00224
L_PCTRL_1: Kd Linear value 24351 5F1F E 1 UNSIGNED_16 10
C00225
L_PCTRL_1: MaxLimit Linear value 24350 5F1E E 1 INTEGER_16 100
C00226
L_PCTRL_1: MinLimit Linear value 24349 5F1D E 1 INTEGER_16 100
C00227
L_PCTRL_1: Acceleration time Linear value 24348 5F1C E 1 UNSIGNED_32 1000
C00228
L_PCTRL_1: Deceleration time Linear value 24347 5F1B E 1 UNSIGNED_32 1000
C00231
L_PCTRL_1: Operating range Linear value 24344 5F18 A 4 INTEGER_16 100
C00233
L_PCTRL_1: Root function Selection list 24342 5F16 E 1 UNSIGNED_8 1
C00234
Oscillation damping influence Linear value 24341 5F15 E 1 UNSIGNED_16 100
C00235
Oscillation damping filter time Linear value 24340 5F14 E 1 UNSIGNED_8 1
C00236
Oscillation damping field weakening Linear value 24339 5F13 E 1 UNSIGNED_8 1
C00241
L_NSet_1: Hyst. NSet reached Linear value 24334 5F0E E 1 INTEGER_16 100
C00242
L_PCTRL_1: Operating mode Selection list 24333 5F0D E 1 UNSIGNED_8 1
C00243
L_PCTRL_1: Accel. time influence Linear value 24332 5F0C E 1 UNSIGNED_32 1000
C00244
L_PCTRL_1: Deceleration time influence Linear value 24331 5F0B E 1 UNSIGNED_32 1000
C00245
L_PCTRL_1: PID output value Linear value 24330 5F0A E 1 INTEGER_16 100
C00246 L_PCTRL_1: nAct_a internal Linear value 24329 5F09 E 1 INTEGER_16 100
C00247 L_PCTRL_1: Window setpoint reached Linear value 24328 5F08 E 1 INTEGER_16 100
C00249
L_PT1_1: Time constant Linear value 24326 5F06 E 1 UNSIGNED_16 1
C00250
L_PT1 2-3: Time constant Linear value 24325 5F05 A 2 INTEGER_16 1
C00251
L_DT1_1: Time constant Linear value 24324 5F04 E 1 INTEGER_16 1
C00252
L_DT1_1: Gain Linear value 24323 5F03 E 1 INTEGER_16 100
C00253
L_DT1_1: Sensitivity Selection list 24322 5F02 E 1 UNSIGNED_8 1
C00254
Kp position controller Linear value 24321 5F01 E 1 UNSIGNED_16 100
C00270
SC: Freq. current setpoint filter Linear value 24305 5EF1 E 1 UNSIGNED_16 10
C00271
SC: Current setpoint filter width Linear value 24304 5EF0 E 1 UNSIGNED_16 10
C00272
SC: Current setpoint filter depth Linear value 24303 5EEF E 1 UNSIGNED_16 1
C00273
Motor moment of inertia Linear value 24302 5EEE E 1 UNSIGNED_32 100
Code Name Type Index Data
dec hex DS DA Data type Factor CINH
Greyed out = display parameter (read only access)
