15 Parameter reference
15.7 Table of attributes
1178
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00274 SC: Max. change in acceleration Linear value 24301 5EED E 1 UNSIGNED_16 10
C00275
Setpoint feedforward control filtering Linear value 24300 5EEC E 1 UNSIGNED_16 10
C00276
SC: max. output voltage Linear value 24299 5EEB E 1 UNSIGNED_8 1
C00280
SC: Filter time const. DC detection Linear value 24295 5EE7 E 1 UNSIGNED_16 1
C00312
System runtimes Linear value 24263 5EC7 A 1 UNSIGNED_32 1000
C00321
Main program runtime Linear value 24254 5EBE A 2 UNSIGNED_16 1
C00322
Transmission mode CAN TxPDOs Linear value 24253 5EBD A 4 UNSIGNED_8 1
C00323
Transmission mode CAN Rx PDOs Linear value 24252 5EBC A 4 UNSIGNED_8 1
C00324
CAN transmit blocking time Linear value 24251 5EBB A 5 UNSIGNED_16 1
C00338
L_Arithmetik_1: Function Selection list 24237 5EAD E 1 UNSIGNED_8 1
C00339
L_Arithmetik_2: Function Selection list 24236 5EAC E 1 UNSIGNED_8 1
C00341
CAN management - error configuration Bit coded 24234 5EAA E 1 UNSIGNED_16 1
C00342
CAN decoupling PDOInOut Bit coded 24233 5EA9 A 2 UNSIGNED_16 1
C00343
LP_CanIn decoupling value Linear value 24232 5EA8 A 16 UNSIGNED_16 1
C00344
LP_CanOut decoupling value Linear value 24231 5EA7 A 16 UNSIGNED_16 1
C00345
CAN error status Selection list 24230 5EA6 E 1 UNSIGNED_8 1
C00347 CAN status HeartBeat producer Selection list 24228 5EA4 A 15 UNSIGNED_8 1
C00349 CAN setting - DIP switch Bit coded 24226 5EA2 E 1 UNSIGNED_16 1
C00350 CAN node address Linear value 24225 5EA1 E 1 UNSIGNED_8 1
C00351
CAN baud rate Selection list 24224 5EA0 E 1 UNSIGNED_8 1
C00352
CAN slave/master Selection list 24223 5E9F E 1 UNSIGNED_8 1
C00353
CAN IN/OUT COBID source Selection list 24222 5E9E A 4 UNSIGNED_8 1
C00354
COBID Bit coded 24221 5E9D A 8 UNSIGNED_32 1
C00355
Active COBID Linear value 24220 5E9C A 8 UNSIGNED_16 1
C00356 CAN time settings Linear value 24219 5E9B A 6 UNSIGNED_16 1
C00357
CAN monitoring times Linear value 24218 5E9A A 4 UNSIGNED_16 1
C00358
CANx_OUT data length Linear value 24217 5E99 A 4 UNSIGNED_8 1
C00359
CAN status Selection list 24216 5E98 E 1 UNSIGNED_8 1
C00360 CAN telegram counter Linear value 24215 5E97 A 14 UNSIGNED_16 1
C00364 CAN MessageError Selection list 24211 5E93 E 1 UNSIGNED_8 1
C00366 Number of CAN SDO channels Selection list 24209 5E91 E 1 UNSIGNED_8 1
C00367
CAN SYNC Rx identifier Bit coded 24208 5E90 E 1 UNSIGNED_16 1
C00368
CAN SYNC Tx identifier Bit coded 24207 5E8F E 1 UNSIGNED_16 1
C00369
CAN sync transmission cycle time Linear value 24206 5E8E E 1 UNSIGNED_16 1
C00370
SyncTxRxTimes Linear value 24205 5E8D A 2 INTEGER_16 1
C00371 CAN ErrorCode Linear value 24204 5E8C A 1 UNSIGNED_16 1
C00372 CAN_Tx_Rx_Error Linear value 24203 5E8B A 4 UNSIGNED_8 1
C00381 CAN Heartbeat producer time Linear value 24194 5E82 E 1 UNSIGNED_16 1
C00385
CAN node addr. HeartBeat producer Linear value 24190 5E7E A 15 UNSIGNED_8 1
C00386
CAN HeartBeat-ConsumerTime Linear value 24189 5E7D A 15 UNSIGNED_16 1
C00387
CAN-GatewayAddr Linear value 24188 5E7C A 1 UNSIGNED_8 1
C00400
LS_PulseGenerator Linear value 24175 5E6F A 3 UNSIGNED_16 1
C00401
CANxInOut: Inversion Bit coded 24174 5E6E A 8 UNSIGNED_16 1
C00407
LP_CanIn mapping Linear value 24168 5E68 A 8 UNSIGNED_32 1
C00408
LP_CanIn mapping selection Selection list 24167 5E67 A 4 UNSIGNED_8 1
C00409
LP_CanIn mapping Linear value 24166 5E66 A 16 UNSIGNED_16 1
C00410
L_SignalMonitor_a: Signal sources Selection list 24165 5E65 A 4 UNSIGNED_16 1
C00411
L_SignalMonitor_b: Signal sources Selection list 24164 5E64 A 4 UNSIGNED_16 1
C00412
L_SignalMonitor_b: Inversion Bit coded 24163 5E63 E 1 UNSIGNED_8 1
C00413
L_SignalMonitor_a: Offs./gain Linear value 24162 5E62 A 8 INTEGER_16 100
Code Name Type Index Data
dec hex DS DA Data type Factor CINH
Greyed out = display parameter (read only access)
