Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1179
15 Parameter reference
15.7 Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00420 Number of encoder increments Linear value 24155 5E5B A 2 UNSIGNED_16 1
C00423
DOx: Delay times Linear value 24152 5E58 A 10 UNSIGNED_16 1000
C00425
Encoder scanning time Selection list 24150 5E56 A 2 UNSIGNED_8 1 CINH
C00434
OxU/I: Gain Linear value 24141 5E4D A 4 INTEGER_16 100
C00435
OxU/I: Offset Linear value 24140 5E4C A 4 INTEGER_16 100
C00436
OxU: Voltage Linear value 24139 5E4B A 2 INTEGER_16 100
C00437 OxI: Current Linear value 24138 5E4A A 2 INTEGER_32 1000
C00439 OxU/I: Input value Linear value 24136 5E48 A 4 INTEGER_16 100
C00440 LS_AnalogIn1: PT1 time constant Linear value 24135 5E47 A 2 UNSIGNED_16 1
C00441
Decoupling AnalogOut Bit coded 24134 5E46 E 1 UNSIGNED_16 1
C00442
AOutx: Decoupling value Linear value 24133 5E45 A 4 INTEGER_16 100
C00443
DIx: Level Bit coded 24132 5E44 A 2 UNSIGNED_16 1
C00444 DOx: Level Bit coded 24131 5E43 A 2 UNSIGNED_16 1
C00445 FreqInxx_nOut_v Linear value 24130 5E42 A 2 INTEGER_16 1
C00446 FreqInxx_nOut_a Linear value 24129 5E41 A 2 INTEGER_16 100
C00447 DigOut decoupling Bit coded 24128 5E40 E 1 UNSIGNED_16 1
C00448
DigOut decoupling value Bit coded 24127 5E3F E 1 UNSIGNED_16 1
C00449
FreqInxx_dnOut_p Linear value 24126 5E3E A 1 INTEGER_32 1
C00453 Keypad: Default manual jog Linear value 24122 5E3A A 2 UNSIGNED_32 1000
C00461
Remote: Acceleration/deceleration time Linear value 24114 5E32 A 1 UNSIGNED_32 1000
C00462
Remote: Control Linear value 24113 5E31 A 2 UNSIGNED_16 1
C00463
Remote: MCK control Bit coded 24112 5E30 A 1 UNSIGNED_32 1
C00464
Remote: Monitoring timeout Linear value 24111 5E2F A 1 UNSIGNED_16 1
C00465
Keypad: Time-out welcome screen Selection list 24110 5E2E E 1 INTEGER_32 1
C00466
Keypad: Default parameter Linear value 24109 5E2D E 1 INTEGER_32 1
C00467
Keypad: Default welcome screen Selection list 24108 5E2C E 1 INTEGER_32 1
C00469
Keypad: Fct. STOP key Selection list 24106 5E2A E 1 INTEGER_32 1 CINH
C00470
LS_ParFree_b Selection list 24105 5E29 A 32 UNSIGNED_8 1
C00471
LS_ParFree Bit coded 24104 5E28 A 32 UNSIGNED_16 1
C00472
LS_ParFree_a Linear value 24103 5E27 A 16 INTEGER_16 100
C00473
LS_ParFree_v Linear value 24102 5E26 A 8 INTEGER_16 1
C00474
LS_ParFree_p Linear value 24101 5E25 A 8 INTEGER_32 1
C00475
LS_ParFreeUnit_1_2 Linear value 24100 5E24 A 32 INTEGER_32 10000
C00476
LS_ParFree_a_2 Linear value 24099 5E23 A 16 INTEGER_16 100
C00477
LS_ParFree_2 Bit coded 24098 5E22 A 32 UNSIGNED_16 1
C00478
LS_ParFree_v_2 Linear value 24097 5E21 A 8 INTEGER_16 1
C00479
LS_ParFree32 Linear value 24096 5E20 A 8 INTEGER_32 1
C00480
LS_DisFree_b Bit coded 24095 5E1F E 1 UNSIGNED_16 1
C00481 LS_DisFree Bit coded 24094 5E1E A 8 UNSIGNED_16 1
C00482 LS_DisFree_a Linear value 24093 5E1D A 8 INTEGER_16 100
C00483 LS_DisFree_p Linear value 24092 5E1C A 8 INTEGER_32 1
C00484 Application units: Offset Linear value 24091 5E1B A 4 INTEGER_16 100
C00485
Application units: Display factor Linear value 24090 5E1A A 4 INTEGER_32 10000
C00486
Application units: Text String 24089 5E19 A 4 VISIBLE_STRING [7]
C00487
Application units Linear value 24088 5E18 A 4 INTEGER_32 100
C00488 L_JogCtrlEdgeDetect_1 Selection list 24087 5E17 A 6 UNSIGNED_8 1
C00490
Position encoder selection Selection list 24085 5E15 E 1 UNSIGNED_8 1
C00495
Speed sensor selection Selection list 24080 5E10 E 1 UNSIGNED_8 1
C00496
Encoder evaluation method DigIn12 Selection list 24079 5E0F E 1 UNSIGNED_8 1 CINH
C00497
Filter time constant Linear value 24078 5E0E A 2 UNSIGNED_16 10
Code Name Type Index Data
dec hex DS DA Data type Factor CINH
Greyed out = display parameter (read only access)
