15 Parameter reference
15.7 Table of attributes
1180
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00505 Password data String 24070 5E06 A 3 VISIBLE_STRING [16]
C00506
PW protection internal config Bit coded 24069 5E05 A 1 UNSIGNED_16 1
C00507
Current password protection Bit coded 24068 5E04 A 1 UNSIGNED_16 1
C00508 PW protection config X6(DIAG) Bit coded 24067 5E03 A 1 UNSIGNED_16 1
C00509
PW protection config X1 (CAN) Bit coded 24066 5E02 A 1 UNSIGNED_16 1
C00510
PW protection config. MCI Bit coded 24065 5E01 A 1 UNSIGNED_16 1
C00517
User menu Linear value 24058 5DFA A 32 INTEGER_32 1000
C00560
Fan switching status Selection list 24015 5DCF A 2 UNSIGNED_8 1
C00561 Failure indication Selection list 24014 5DCE A 5 UNSIGNED_8 1
C00563 Current monitoring: Delay time Linear value 24012 5DCC A 1 UNSIGNED_32 1000
C00565
Resp. to mains phase failure Selection list 24010 5DCA E 1 UNSIGNED_8 1
C00566
Resp. to fan failure Selection list 24009 5DC9 E 1 UNSIGNED_8 1
C00567
Resp. to speed controller limited Selection list 24008 5DC8 E 1 UNSIGNED_8 1
C00569
Resp. to peak current Selection list 24006 5DC6 A 1 UNSIGNED_8 1
C00570
Resp. to controller limitations Selection list 24005 5DC5 A 4 UNSIGNED_8 1
C00571
Resp. to wrong controller setting Selection list 24004 5DC4 A 2 UNSIGNED_8 1
C00572
Brake resistor overload threshold Linear value 24003 5DC3 E 1 UNSIGNED_8 1
C00574
Resp. to brake resist. overtemp. Selection list 24001 5DC1 E 1 UNSIGNED_8 1
C00576
SC: Optimisation of field feedforward
control
Linear value 23999 5DBF E 1 UNSIGNED_16 1
C00577
SC: Vp field weakening controller Linear value 23998 5DBE E 1 UNSIGNED_16 10000
C00578
SC: Tn field weakening controller Linear value 23997 5DBD E 1 UNSIGNED_16 10
C00579
Resp. to max. speed/output freq. reached Selection list 23996 5DBC E 1 UNSIGNED_8 1
C00580
Resp. to operating system error Selection list 23995 5DBB A 1 UNSIGNED_8 1
C00581
Resp. to LS_SetError_x Selection list 23994 5DBA A 8 UNSIGNED_8 1
C00582
Resp. to heatsink temp.> shutdown temp.
-5°C
Selection list 23993 5DB9 E 1 UNSIGNED_8 1
C00584
Resp. to current monitoring Selection list 23991 5DB7 A 1 UNSIGNED_8 1
C00585
Resp. to motor overtemp. PTC Selection list 23990 5DB6 E 1 UNSIGNED_8 1
C00586
Resp. open circuit HTL encoder Selection list 23989 5DB5 E 1 UNSIGNED_8 1
C00588
Resp. to max. speed at switching freq. Selection list 23987 5DB3 E 1 UNSIGNED_8 1
C00590
Resp. to switch. frequency red. Selection list 23985 5DB1 E 1 UNSIGNED_8 1
C00592
Resp. to CAN bus connection Selection list 23983 5DAF A 5 UNSIGNED_8 1
C00593
Resp. to CANx_IN monitoring Selection list 23982 5DAE A 4 UNSIGNED_8 1
C00594
Resp. to control word error Selection list 23981 5DAD A 2 UNSIGNED_8 1
C00595
MCK: Resp. to MCK error Selection list 23980 5DAC A 17 UNSIGNED_8 1
C00597
Resp. to motor phase failure Selection list 23978 5DAA E 1 UNSIGNED_8 1
C00598
Resp. to open circuit AINx Selection list 23977 5DA9 A 2 UNSIGNED_8 1
C00599
Motor phase failure threshold Linear value 23976 5DA8 E 1 INTEGER_16 100
C00600
Resp. to DC bus voltage Selection list 23975 5DA7 A 1 UNSIGNED_8 1
C00601
Delayed resp. to fault: DC bus overvoltage Linear value 23974 5DA6 A 1 UNSIGNED_16 1000
C00602
Resp. to earth fault Selection list 23973 5DA5 E 1 UNSIGNED_8 1
C00604
Resp. to device overload (Ixt) Selection list 23971 5DA3 E 1 UNSIGNED_8 1
C00605
Resp. to feedback Selection list 23970 5DA2 A 1 UNSIGNED_8 1
C00606
Resp. to motor overload (I²xt) Selection list 23969 5DA1 E 1 UNSIGNED_8 1
C00607
Resp. to max. freq. feedb. DIG12/67 Selection list 23968 5DA0 E 1 UNSIGNED_8 1
C00608
Resp. to maximum torque Selection list 23967 5D9F E 1 UNSIGNED_8 1
C00609
Resp. to maximum current Selection list 23966 5D9E E 1 UNSIGNED_8 1
C00620
System connection list: 16-bit Selection list 23955 5D93 A 111 UNSIGNED_16 1
C00621
System connection list: Bool Selection list 23954 5D92 A 199 UNSIGNED_16 1
C00622
System connection list: Angle Selection list 23953 5D91 A 25 UNSIGNED_16 1
Code Name Type Index Data
dec hex DS DA Data type Factor CINH
Greyed out = display parameter (read only access)
