Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1181
15 Parameter reference
15.7 Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00630 L_Limit 1-2: Min/Max Linear value 23945 5D89 A 4 INTEGER_16 100
C00631
L_LimitPhi 1-3: Min/Max Linear value 23944 5D88 A 6 INTEGER_32 1
C00632
L_NSet_1: Max. skip freq. Linear value 23943 5D87 A 3 INTEGER_16 100
C00633
L_NSet_1: Min. skip freq. Linear value 23942 5D86 A 3 INTEGER_16 100
C00634
L_NSet_1: wState Bit coded 23941 5D85 E 1 UNSIGNED_16 1
C00635 L_NSet_1: nMaxLimit Linear value 23940 5D84 E 1 INTEGER_16 100
C00636
L_NSet_1: nMinLimit Linear value 23939 5D83 E 1 INTEGER_16 100
C00637
L_NSet_1: Output blocking zones Linear value 23938 5D82 E 1 INTEGER_16 100
C00638 L_NSet_1: Output ramp rounding Linear value 23937 5D81 E 1 INTEGER_16 100
C00639 L_NSet_1: Output add.value Linear value 23936 5D80 E 1 INTEGER_16 100
C00640 L_NSet_1: nNOut_a Linear value 23935 5D7F E 1 INTEGER_16 100
C00643 Resp. to PLI monitoring Selection list 23932 5D7C A 1 UNSIGNED_8 1
C00650
L_Arithmetik 3-5: Function Selection list 23925 5D75 A 3 UNSIGNED_8 1
C00653
Sensibility - Setpoint feedforward control Selection list 23922 5D72 A 1 UNSIGNED_8 1
C00654
Source of diff. setpoint feedforward
control
Selection list 23921 5D71 A 1 UNSIGNED_8 1
C00660
L_FixSet_a_1: Analog values Linear value 23915 5D6B A 16 INTEGER_16 100
C00661
L_FixSet_w_1: Fixed values Linear value 23914 5D6A A 16 UNSIGNED_16 1
C00662
L_FixSet_w_2: Fixed values Linear value 23913 5D69 A 16 UNSIGNED_16 1
C00670
L_OffsetGainP_1: Gain Linear value 23905 5D61 E 1 INTEGER_32 10000
C00671
L_OffsetGainP_2: Gain Linear value 23904 5D60 E 1 INTEGER_32 10000
C00672
L_OffsetGainP_3: Gain Linear value 23903 5D5F E 1 INTEGER_32 10000
C00673
L_OffsetGainPhiP 1-2: Offset Linear value 23902 5D5E A 2 INTEGER_32 1
C00674
L_OffsetGainPhiP 1-2: Gain Linear value 23901 5D5D A 2 INTEGER_32 1
C00677
L_GainOffsetP 1-3: Parameter Linear value 23898 5D5A A 6 INTEGER_16 100
C00678
L_GainOffsetPhiP 1-2: Parameter Linear value 23897 5D59 A 4 INTEGER_32 1
C00679
L_MulDiv_2: Parameter Linear value 23896 5D58 A 2 INTEGER_16 1
C00680
L_Compare_1: Fct. Selection list 23895 5D57 E 1 UNSIGNED_8 1
C00681
L_Compare_1: Hysteresis Linear value 23894 5D56 E 1 INTEGER_16 100
C00682
L_Compare_1: Window Linear value 23893 5D55 E 1 INTEGER_16 100
C00685
L_Compare_2: Fct. Selection list 23890 5D52 E 1 UNSIGNED_8 1
C00686
L_Compare_2: Hysteresis Linear value 23889 5D51 E 1 INTEGER_16 100
C00687
L_Compare_2: Window Linear value 23888 5D50 E 1 INTEGER_16 100
C00690
L_Compare_3: Fct. Selection list 23885 5D4D E 1 UNSIGNED_8 1
C00691
L_Compare_3: Hysteresis Linear value 23884 5D4C E 1 INTEGER_16 100
C00692
L_Compare_3: Window Linear value 23883 5D4B E 1 INTEGER_16 100
C00693
L_Compare 4-5: Fct. Selection list 23882 5D4A A 2 UNSIGNED_8 1
C00694
L_Compare 4-5: Hysteresis Linear value 23881 5D49 A 2 INTEGER_16 100
C00695
L_Compare 4-5: Window Linear value 23880 5D48 A 2 INTEGER_16 100
C00696
L_OffsetGainP_1: Offset Linear value 23879 5D47 E 1 INTEGER_16 100
C00697
L_OffsetGainP_2: Offset Linear value 23878 5D46 E 1 INTEGER_16 100
C00698
L_OffsetGainP_3: Offset Linear value 23877 5D45 E 1 INTEGER_16 100
C00699
L_MulDiv_1: Parameter Linear value 23876 5D44 A 2 INTEGER_16 1
C00700
LA_NCtrl: Analog connection list Selection list 23875 5D43 A 29 UNSIGNED_16 1
C00701
LA_NCtrl: Digital connection list Selection list 23874 5D42 A 48 UNSIGNED_16 1
C00710
LA_TabPos: Analog connection list Selection list 23865 5D39 A 31 UNSIGNED_16 1
C00711
LA_TabPos: Digital connection list Selection list 23864 5D38 A 56 UNSIGNED_16 1
C00712
LA_TabPos: phi connection list Selection list 23863 5D37 A 3 UNSIGNED_16 1
C00720
L_DigitalDelay_1: Delay Linear value 23855 5D2F A 2 UNSIGNED_32 1000
C00721
L_DigitalDelay 2..3: Delay Linear value 23854 5D2E A 4 UNSIGNED_32 1000
Code Name Type Index Data
dec hex DS DA Data type Factor CINH
Greyed out = display parameter (read only access)
