15 Parameter reference
15.7 Table of attributes
1182
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00725 Current switching frequency Selection list 23850 5D2A E 1 UNSIGNED_8 1
C00727 LS_Keypad digital values Linear value 23848 5D28 A 8 UNSIGNED_8 1
C00728
Analog values - keypad Linear value 23847 5D27 A 3 INTEGER_16 100
C00729
Remote: Setpoint selection Linear value 23846 5D26 A 2 INTEGER_16 100
C00760
LA_SwitchPos: Analog connection list Selection list 23815 5D07 A 25 UNSIGNED_16 1
C00761
LA_SwitchPos: Digital connection list Selection list 23814 5D06 A 47 UNSIGNED_16 1
C00800
L_MPot_1: Upper limit Linear value 23775 5CDF E 1 INTEGER_16 100
C00801
L_MPot_1: Lower limit Linear value 23774 5CDE E 1 INTEGER_16 100
C00802
L_MPot_1: Acceleration time Linear value 23773 5CDD E 1 UNSIGNED_16 10
C00803
L_MPot_1: Deceleration time Linear value 23772 5CDC E 1 UNSIGNED_16 10
C00804
L_MPot_1: Inactive fct. Selection list 23771 5CDB E 1 UNSIGNED_8 1
C00805
L_MPot_1: Init fct. Selection list 23770 5CDA E 1 UNSIGNED_8 1
C00806
L_MPot_1: Use Selection list 23769 5CD9 E 1 UNSIGNED_8 1
C00807
L_NLim_1: Max.SkipFrq. Linear value 23768 5CD8 A 3 INTEGER_16 100
C00808
L_NLim_1: Min.SkipFrq. Linear value 23767 5CD7 A 3 INTEGER_16 100
C00809
L_NLim_2: Max.SkipFrq. Linear value 23766 5CD6 A 3 INTEGER_16 100
C00810
L_NLim_2: Min.SkipFrq. Linear value 23765 5CD5 A 3 INTEGER_16 100
C00811
L_NLim_1: Current output value Linear value 23764 5CD4 A 2 INTEGER_16 100
C00812 L_NLim: Current status Bit coded 23763 5CD3 A 2 UNSIGNED_16 1
C00820 L_DigitalLogic_1: Function Selection list 23755 5CCB E 1 UNSIGNED_8 1
C00821
L_DigitalLogic_1: Truth table Selection list 23754 5CCA A 24 UNSIGNED_8 1
C00822
L_DigitalLogic_2: Function Selection list 23753 5CC9 E 1 UNSIGNED_8 1
C00823
L_DigitalLogic_2: Truth table Selection list 23752 5CC8 A 24 UNSIGNED_8 1
C00824
L_DigitalLogic5_1: Function Selection list 23751 5CC7 E 1 UNSIGNED_8 1
C00825
L_DigitalLogic5_1: Truth table Selection list 23750 5CC6 A 32 UNSIGNED_8 1
C00826
L_DigitalLogic5_2: Function Selection list 23749 5CC5 E 1 UNSIGNED_8 1
C00827
L_DigitalLogic5_2: Truth table Selection list 23748 5CC4 A 32 UNSIGNED_8 1
C00828
L_DigitalLogic_3: Function Selection list 23747 5CC3 E 1 UNSIGNED_8 1
C00829
L_DigitalLogic_3: truth table Selection list 23746 5CC2 A 24 UNSIGNED_8 1
C00830
16-bit inputs [%] Linear value 23745 5CC1 A 105 INTEGER_16 100
C00831 16-bit inputs Bit coded 23744 5CC0 A 105 UNSIGNED_16 1
C00832 16-bit inputs [incr./ms] Linear value 23743 5CBF A 105 INTEGER_16 1
C00833 Binary inputs Selection list 23742 5CBE A 131 UNSIGNED_8 1
C00834 32-bit inputs [incr] Linear value 23741 5CBD A 12 INTEGER_32 1
C00835 16-bit inputs [%] (Set2) Linear value 23740 5CBC A 162 INTEGER_16 100
C00836 16-bit inputs (Set2) Bit coded 23739 5CBB A 162 UNSIGNED_16 1
C00837 16-bit inputs [incr./ms] (Set2) Linear value 23738 5CBA A 162 INTEGER_16 1
C00838 Binary inputs (Set2) Selection list 23737 5CB9 A 213 UNSIGNED_8 1
C00839 32-bit inputs [incr] (Set2) Linear value 23736 5CB8 A 96 INTEGER_32 1
C00840 16-bit inputs I/O level [%] Linear value 23735 5CB7 A 111 INTEGER_16 100
C00841 16-bit inputs I/O level Bit coded 23734 5CB6 A 111 UNSIGNED_16 1
C00843 Binary inputs I/O level Selection list 23732 5CB4 A 199 UNSIGNED_8 1
C00844 32-bit inputs I/O level [incr] Linear value 23731 5CB3 A 25 INTEGER_32 1
C00866 CAN input words Bit coded 23709 5C9D A 16 UNSIGNED_16 1
C00868 CAN output words Bit coded 23707 5C9B A 16 UNSIGNED_16 1
C00876 MCI input words Bit coded 23699 5C93 A 16 UNSIGNED_16 1
C00877 MCI output words Bit coded 23698 5C92 A 16 UNSIGNED_16 1
C00890 MCI_InOut: Inversion Bit coded 23685 5C85 A 4 UNSIGNED_16 1
C00905
Motor phase direction of rotation Selection list 23670 5C76 E 1 UNSIGNED_8 1 CINH
C00909
Speed limitation Linear value 23666 5C72 A 2 INTEGER_16 100
Code Name Type Index Data
dec hex DS DA Data type Factor CINH
Greyed out = display parameter (read only access)
