Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1183
15 Parameter reference
15.7 Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00910 Frequency limitation Linear value 23665 5C71 A 2 UNSIGNED_16 1
C00915
Motor cable length Linear value 23660 5C6C E 1 UNSIGNED_16 10
C00916
Motor cable cross-section Linear value 23659 5C6B E 1 UNSIGNED_16 100
C00917
Motor cable resistance Linear value 23658 5C6A E 1 UNSIGNED_16 1
C00918 SC: Start motor magnetising current Linear value 23657 5C69 E 1 UNSIGNED_8 1
C00919
Load moment of inertia Linear value 23656 5C68 A 1 UNSIGNED_32 100
C00920
Rated device currents Linear value 23655 5C67 A 8 UNSIGNED_16 10
C00937 Field-oriented motor currents Linear value 23638 5C56 A 2 INTEGER_16 100
C00938 PSM: Maximum motor current field
weakening
Linear value 23637 5C55 E 1 UNSIGNED_16 100
C00939
Ultimate motor current Linear value 23636 5C54 E 1 UNSIGNED_16 10
C00940
L_ConvW numerator Linear value 23635 5C53 A 4 INTEGER_16 1
C00941
L_ConvW denominator Linear value 23634 5C52 A 4 INTEGER_16 1
C00942
L_ConvW conversion method Selection list 23633 5C51 A 4 UNSIGNED_8 1
C00950
L_Interpolator_1: Activation FB functions Selection list 23625 5C49 A 3 UNSIGNED_8 1
C00951
L_Interpolator_1: No. of interpolation
steps
Linear value 23624 5C48 E 1 UNSIGNED_16 1
C00952
L_Interpolator_1: Limit value - error cycles Linear value 23623 5C47 E 1 UNSIGNED_16 1
C00953
L_Interpolator_1: Speed-up Linear value 23622 5C46 E 1 UNSIGNED_8 1
C00959
L_Curve: Current output value Linear value 23616 5C40 A 3 INTEGER_16 100
C00960 L_Curve_1: Selected curve type Selection list 23615 5C3F A 1 UNSIGNED_8 1
C00961
L_Curve_1: Input limitation Linear value 23614 5C3E A 2 INTEGER_16 100
C00963
L_Curve_1: Table X-values Linear value 23612 5C3C A 32 INTEGER_16 1
C00964
L_Curve_1: Table Y-values Linear value 23611 5C3B A 32 INTEGER_16 1
C00965
Max. motor speed Linear value 23610 5C3A E 1 UNSIGNED_16 1
C00966
VFC: Time const. slip comp. Linear value 23609 5C39 E 1 UNSIGNED_16 1
C00967
VFC: Frequency interpol. point n Linear value 23608 5C38 A 11 INTEGER_16 10
C00968
VFC: Voltage interpol. point n Linear value 23607 5C37 A 11 UNSIGNED_16 100
C00969
Motor parameters Linear value 23606 5C36 A 1 UNSIGNED_8 1
C00970 Rated device voltage Linear value 23605 5C35 A 1 UNSIGNED_16 1
C00971 VFC: V/f +encoder limitation Linear value 23604 5C34 A 2 UNSIGNED_16 100
C00972
VFC: Vp V/f +encoder Linear value 23603 5C33 E 1 UNSIGNED_16 1000
C00973
VFC: Ti V/f +encoder Linear value 23602 5C32 E 1 UNSIGNED_16 10
C00975
VFC-ECO: Vp CosPhi controller Linear value 23600 5C30 E 1 UNSIGNED_16 1000
C00976
VFC-ECO: Ti CosPhi controller Linear value 23599 5C2F E 1 UNSIGNED_16 10
C00977
VFC-ECO: Minimum voltage V/f Linear value 23598 5C2E E 1 INTEGER_16 100
C00978
VFC-ECO: Voltage reduction Linear value 23597 5C2D E 1 INTEGER_16 1
C00979 Cosine phi Linear value 23596 5C2C A 2 INTEGER_16 100
C00980 Power display Linear value 23595 5C2B A 4 INTEGER_32 1000
C00981 Energy display Linear value 23594 5C2A A 2 INTEGER_32 100
C00982 VFC-ECO: Voltage reduction ramp Linear value 23593 5C29 E 1 UNSIGNED_8 10
C00983
Delay Linear value 23592 5C28 A 2 UNSIGNED_16 1
C00985
SLVC: Gain of field current controller Linear value 23590 5C26 E 1 INTEGER_16 100
C00986
SLVC: Gain of cross current controller Linear value 23589 5C25 E 1 INTEGER_16 100
C00987
Inverter motor brake: nAdd Linear value 23588 5C24 E 1 INTEGER_16 1
C00988
Inverter motor brake: PT1 filter time Linear value 23587 5C23 E 1 INTEGER_16 10
C00989
Restart on the fly: Flying restart frequency
fd_add
Linear value 23586 5C22 A 1 INTEGER_16 100
C00990
Flying restart fct.: Activate Selection list 23585 5C21 E 1 UNSIGNED_8 1 CINH
C00991
Flying restart fct.: Process Selection list 23584 5C20 E 1 UNSIGNED_16 1
C00992
Flying restart: Start frequency Linear value 23583 5C1F E 1 INTEGER_16 1
Code Name Type Index Data
dec hex DS DA Data type Factor CINH
Greyed out = display parameter (read only access)
