5 Motor control (MCTRL)
5.11 Encoder/feedback system
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
General procedure
(if the encoder is connected to the digital inputs DI1 and DI2)
1. Define the function of the digital inputs DI1 and DI2 in C00115/1
.
2. Set the encoder increments in C00420/1
.
3. Select "1: Encoder signal FreqIn12" in C00495/1
.
4. Adapt the filter time of the speed measurement in C00497/1
.
5. In the case of encoders with a very low resolution (number of increments < 120 increments):
Change the encoder evaluation procedure in C00496
if necessary.
Settings for HTL encoder at DI1/DI2
C00115/1
Fct. DI 1/2 200kHz
• Function of the digital inputs DI1 and DI2
0: DI1(6)=In / DI2(7)=In
C00420/1
FreqIn12: Encoder increment
• If the digital inputs DI1 and DI2 are used as
encoder inputs.
128 Incr./rev.
C00425/1
FreqIn12: Encoder scanning time
• If the digital inputs DI1 and DI2 are used as
encoder inputs.
10 ms
C00497/1
FreqIn12: Encoder filter time
• If the digital inputs DI1 and DI2 are used as
encoder inputs.
1.0 ms
C00496
Encoder evaluation method DigIn12 ( 282) 2: Comb. encoder method
C00055/1 Actual value - HTL encoder FreqIn12 - rpm
Settings for HTL encoder at DI6/DI7
C00115/2
Fct. DI 6/7 10kHz
• Function of the digital inputs DI6 and DI7
0: DI1(6)=In / DI2(7)=In
C00420/2
FreqIn67: Encoder increment
• If the digital inputs DI6 and DI7 are used as
encoder inputs.
128 Incr./rev.
C00425/2
FreqIn67: Encoder scanning time
• If the digital inputs DI6 and DI7 are used as
encoder inputs.
10 ms
C00497/2
FreqIn67: Encoder filter time
• If the digital inputs DI6 and DI7 are used as
encoder inputs.
1.0 ms
C00055/2 Actual value - HTL encoder FreqIn67 - rpm
Monitoring
C00586
Resp. open circuit HTL encoder
Encoder open-circuit monitoring
( 311)
1: Fault
C00579
Resp. max. speed/output freq. reached 0: No Reaction
C00607
Resp. to max. freq. feedb. DIG12/67 1: Fault
Parameters Info Lenze setting
Value Unit
Greyed out = display parameter
