Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 655
9 Diagnostics & error management
9.9 Error messages of the operating system
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
xx.0144.00001 0x2c01 11265 9437185 PS01: No memory module Warning - 0x6300
xx.0144.00002
0x2c02 11266 9437186 PS02: Par. set invalid Fault -0x6300
xx.0144.00003
0x2c03 11267 9437187 PS03: Par. set device invalid Fault -0x6300
xx.0144.00004
0x2c04 11268 9437188 PS04: Invalid MCI par. set Fault -0x6300
xx.0144.00007
0x2c07 11271 9437191 PS07: Par. mem. module invalid Fault -0x6300
xx.0144.00008
0x2c08 11272 9437192 PS08: Par. device invalid Fault -0x6300
xx.0144.00009
0x2c09 11273 9437193 PS09: Par. format invalid Fault -0x6300
xx.0144.00010
0x2c0a 11274 9437194 PS10: Memory module link invalid Fault -
xx.0123.00200
0x17c8 6088 8061128 Sd10: Speed limit for feedback system 12 Fault C00607 0x7300
xx.0123.00201
0x17c9 6089 8061129 Sd11: Speed limit for feedback system 67 Fault C00607 0x7300
xx.0123.00207
0x17cf 6095 8061135 Sd15: Open circuit HTL 4-fold Fault C00605/1
xx.0123.00205 0x17cd 6093 8061133 Sd3: Open circuit HTL 2-fold or 4-fold Fault C00586 0x7300
xx.0111.00002
0x0b02 2818 7274498 Su02: One mains phase is missing Warning C00565 0x3000
xx.0111.00003
0x0b03 2819 7274499 Su03: Too frequent mains switching Fault -0x3000
xx.0111.00004
0x0b04 2820 7274500 Su04: CU insufficiently supplied Warning - 0x3000
xx.0111.00006
0x0b06 2822 7274502 Su06: Power input overload Fault -0x3000
Freely configurable user error messages (see LS_SetError_1 and LS_SetError_2)
xx.0980.00001
25600
dec
+ C161/1* User error 1 No Reaction C00581/1 0x6200
xx.0981.00002
25856
dec
+ C161/2* User error 2 No Reaction C00581/2 0x6200
xx.0982.00003
26112
dec
+ C161/3* User error 3 No Reaction C00581/3 0x6200
xx.0983.00004
26368
dec
+ C161/4* User error 4 No Reaction C00581/4 0x6200
xx.0984.00001
26624
dec
+ C161/5* User error 5 No Reaction C00581/5 0x6200
xx.0985.00002
26880
dec
+ C161/6* User error 6 No Reaction C00581/6 0x6200
xx.0986.00003
27136
dec
+ C161/7* User error 7 No Reaction C00581/7 0x6200
xx.0987.00004
27392
dec
+ C161/8* User error 8 No Reaction C00581/8 0x6200
* Only the lower 8 bits of the adjustable error ID (C161/x
) can be used.
Error number Display in Error message Response
(Lenze setting)
Adjustable
in
CAN
Emergency
Error Code
32 bits 16 bits
hex
16 bits
dec
C00162/1
