9 Diagnostics & error management
9.9 Error messages of the operating system
654
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
xx.0184.00009 0x5409 21513 12058633 Ck17: direction conflict Ccw Information -
xx.0184.00010
0x540a 21514 12058634 Ck18: direction conflict Cw Information -
xx.0145.00035
0x2d23 11555 9502755 dF10: AutoTrip reset Fault C00189 0xF000
xx.0145.00014
0x2d0e 11534 9502734 dF14: SW-HW invalid Fault -
xx.0145.00024
0x2d18 11544 9502744 dF18: BU RCOM error Fault -0x6100
xx.0145.00033
0x2d21 11553 9502753 dF21: BU watchdog Fault -0x6100
xx.0145.00034
0x2d22 11554 9502754 dF22: CU Watchdog Fault -0x6100
xx.0145.00025
0x2d19 11545 9502745 dF25: CU RCOM error Fault -0x6100
xx.0145.00026
0x2d1a 11546 9502746 dF26: Appl. watchdog No Reaction C00580/1 0x6200
xx.0145.00050
0x2d32 11570 9502770 dF50: Retain error Fault -0x6100
xx.0145.00051
0x2d33 11571 9502771 dF51: CuCcr error Fault -0x6100
xx.0145.00052
0x2d34 11572 9502772 dF52: BuCcr error Fault -0x6100
xx.0400.00009
0x1a09 6665 26214409 dH09: EEPROM power unit Fault -0x5500
xx.0400.00016
0x1a10 6672 26214416 dH10: Fan failure Warning C00566 0x5000
xx.0400.00104
0x1a68 6760 26214504 dH68: Adjustment data error CU Fault -0x5500
xx.0400.00105
0x1a69 6761 26214505 dH69: Adjustment data error BU Fault -0x5500
xx.0400.00106
0x1a6a 6762 26214506 dH70: ControlUnit is unequal to BaseUnit Fault -0x5500
xx.0123.00094
0x175e 5982 8061022 FC01: Switching frequency reduction No Reaction C00590 0x2000
xx.0123.00095
0x175f 5983 8061023 FC02: Maximum speed for Fchop No Reaction C00588 0xF000
xx.0123.00099
0x1763 5987 8061027 FC03: Limitation field controller No Reaction C00570/4 0xF000
xx.0123.00057
0x1739 5945 8060985 Id1: Motor data identification error Fault -0xF000
xx.0123.00058
0x173a 5946 8060986 Id3: CINH identification WarningLocked - 0xF000
xx.0123.00059
0x173b 5947 8060987 Id4: Resistance identification error Warning - 0xF000
xx.0123.00074
0x174a 5962 8061002 Id5: Pole position identification error Fault C00643/1
xx.0123.00060 0x173c 5948 8060988 Id7: Motor control does not match motor data Information C00571/1 0xF000
xx.0123.00061
0x173d 5949 8060989 Id8: Speed sensor has not been set Fault C00571/2 0x7120
xx.0123.00145
0x1791 6033 8061073 LP1: Motor phase failure No Reaction C00597 0x3000
xx.0123.00015
0x170f 5903 8060943 LU: DC bus undervoltage Trouble C00600/1 0x3100
xx.0123.00016
0x1710 5904 8060944 oC1: Power section - short circuit Fault -0x2000
xx.0123.00030
0x171e 5918 8060958 oC10: Maximum current reached No Reaction C00609 0x2000
xx.0123.00071
0x1747 5959 8060999 oC11: Clamp operation active Fault -0xF000
xx.0123.00065
0x1741 5953 8060993 oC12: I2xt brake resistor overload Fault -0xF000
xx.0123.00090
0x175a 5978 8061018 oC13: Maximum current for Fch exceeded Fault -0xF000
xx.0123.00096
0x1760 5984 8061024 oC14: Direct-axis current controller limitation No Reaction C00570/1 0xF000
xx.0123.00097
0x1761 5985 8061025 oC15: Cross current controller limitation No Reaction C00570/2 0xF000
xx.0123.00098
0x1762 5986 8061026 oC16: Torque controller limitation No Reaction C00570/3 0xF000
xx.0123.00031
0x171f 5919 8060959 oC17: Clamp sets pulse inhibit No Reaction C00569/1 0xF000
xx.0123.00034
0x1722 5922 8060962 oC18: Current monitoring overload No Reaction C00584/1 0x2000
xx.0123.00066
0x1742 5954 8060994 oC19: short circuit of brake resistor Fault -
xx.0123.00017
0x1711 5905 8060945 oC2: Power section - earth fault Fault -0x2000
xx.0119.00050
0x1332 4914 7798834 oC5: Ixt overload Warning C00604 0x2000
xx.0123.00105
0x1769 5993 8061033 oC6: I2xt motor overload Warning C00606 0x2000
xx.0123.00007
0x1707 5895 8060935 oC7: Motor overcurrent Fault -0x2000
xx.0119.00001
0x1301 4865 7798785 oH1: Heatsink overtemperature Fault -0x4000
xx.0119.00015
0x130f 4879 7798799 oH3: Motor temperature (X106) triggered Fault C00585 0x4000
xx.0119.00000
0x1300 4864 7798784 oH4: Heatsink temp. > shutdown temp. -5°C No Reaction C00582 0x4000
xx.0123.00032
0x1720 5920 8060960 oS1: Maximum speed limit reached No Reaction C00579 0x8400
xx.0123.00033
0x1721 5921 8060961 oS2: Max. motor speed Fault -0x8400
xx.0123.00001
0x1701 5889 8060929 ot1: Max. torque reached No Reaction C00608 0x8300
xx.0123.00093
0x175d 5981 8061021 ot2: Speed controller output limited No Reaction C00567 0xF000
xx.0123.00014
0x170e 5902 8060942 OU: DC bus overvoltage Trouble -0x3100
Error number Display in Error message Response
(Lenze setting)
Adjustable
in
CAN
Emergency
Error Code
32 bits 16 bits
hex
16 bits
dec
C00162/1
