Action Yes No
Step 3
Make sure that all the trays and tray inserts are properly installed.
Does the problem remain?
Go to step 4. The problem is
solved.
Step 4
Enter the Diagnostics menu, and then navigate to:
Input tray quick print >select source tray > Single
Does the problem remain?
Go to step 5. The problem is
solved.
Step 5
a Remove the duplex/MPF tray. See “Duplex/MPF tray removal”
on page 434.
b Enter the Diagnostics menu, and then navigate to:
Printer diagnostics and adjustments > Sensor tests
c Find the sensor (Tray 1 pass-through).
Does the sensor status change while toggling the sensor?
Go to step 9. Go to step 6.
Step 6
a Remove the right cover. See “Right cover removal” on
page 420.
b Check the sensor cable J73 on the controller board for proper
connection.
Is the cable properly connected?
Go to step 8. Go to step 7.
Step 7
Reseat the cable.
Does the problem remain?
Go to step 8. The problem is
solved.
Step 8
Replace the sensor. See
“Sensor (tray 1 pass‑through) removal”
on page 468.
Does the problem remain?
Go to step 9. The problem is
solved.
Step 9
Check the source tray pick roller for improper installation,
contamination, and damage.
Note: Make sure that the pick roller is fully pressed to its feeder
shaft. A click will be heard indicating a proper engagement
between the latches and the shaft.
Is the pick roller properly installed and free of contamination and
damage?
Go to step 11. Go to step 10.
