Action Yes No
Step 3
Remove the paper fragments and partially fed paper.
Does the problem remain?
Go to step 4. The problem is
solved.
Step 4
Clear the optional bin paper path rollers of any dirt and
contamination.
Does the problem remain?
Go to step 5. The problem is
solved.
Step 5
a Enter the Diagnostics menu, and then navigate to:
Output bin quick feed > Feed to all bins
b To uc h Single or Continuous.
Does the problem remain?
Go to step 6. The problem is
solved.
Step 6
a Enter the Diagnostics menu, and then navigate to:
Output device adjustments/tests > Output device sensor
tests > High capacity output expander
b Find the sensor (Pass-through).
Does the sensor status change while toggling the sensor?
Go to step 10. Go to step 7.
Step 7
a Remove the HCOE left cover. See “HCOE left cover removal”
on page 550.
b Reseat the sensor cable on the HCOE controller board.
Does the problem remain?
Go to step 8. The problem is
solved.
Step 8
Check the sensor for improper installation, contamination, and
damage.
Is the sensor properly installed and free of contamination and
damage?
Go to step 10. Go to step 9.
Step 9
Reinstall or replace the sensor. See
“Sensor (HCOE pass‑through)
removal” on page 578.
Does the problem remain?
Go to step 10. The problem is
solved.
4064
Diagnostics and troubleshooting
201
