Action Yes No
Step 10
a Remove the HCOE left cover. See “HCOE left cover removal”
on page 550.
b Reseat the cable on the motor (HCOE diverter) and on the
HCOE controller board.
Does the problem remain?
Go to step 11. The problem is
solved.
Step 11
Check the motor (HCOE diverter) for improper installation and
damage.
Is the motor properly installed and free of damage?
Go to step 13. Go to step 12.
Step 12
Reinstall or replace the motor. See
“Motor (HCOE diverter)
removal” on page 556.
Does the problem remain?
Go to step 13. The problem is
solved.
Step 13
Check the HCOE diverter plunger for improper installation and
damage.
Is the diverter plunger properly installed and free of damage?
Go to step 15. Go to step 14.
Step 14
Reinstall or replace the diverter plunger. See
“HCOE diverter
plunger assembly removal” on page 564.
Does the problem remain?
Go to step 15. The problem is
solved.
Step 15
Reseat the cable on the motor (HCOE transport) and on the HCOE
controller board.
Does the problem remain?
Go to step 16. The problem is
solved.
Step 16
Check the motor (HCOE transport) for improper installation and
damage.
Is the motor properly installed and free of damage?
Go to step 18. Go to step 17.
Step 17
Reinstall or replace the motor. See
“Motor (HCOE transport)
removal” on page 568.
Does the problem remain?
Go to step 18. The problem is
solved.
4064
Diagnostics and troubleshooting
202
