Action Yes No
Step 13
Check the tamper drive belt for improper installation, wear, and
damage.
Is the drive belt properly installed and free of wear and damage?
Go to step 15. Go to step 14.
Step 14
Reinstall or replace the drive belt.
Does the problem remain?
Go to step 15. The problem is
solved.
Step 15
Check the tamper aligner for improper installation and damage.
Is the tamper aligner properly installed and free of damage?
Go to step 17. Go to step 16.
Step 16
Reinstall or replace the tamper aligner.
Does the problem remain?
Go to step 17. The problem is
solved.
Step 17
Check the tamper gear for improper installation and damage.
Is the gear properly installed and free of damage?
Go to step 19. Go to step 18.
Step 18
Reinstall or replace the gear.
Does the problem remain?
Go to step 19. The problem is
solved.
Step 19
Make sure that the controller board of the aected optional bin is
properly installed. Reseat all the cables on the controller board.
Does the problem remain?
Go to step 20. The problem is
solved.
Step 20
Check the aected controller board and its connector pins for
damage.
Are the bin controller board and its connectors free of damage?
Contact the next
level of support.
Go to step 21.
Step 21
Replace the bin controller board. See
“Staple, hole punch finisher
controller board removal” on page 705.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
4064
Diagnostics and troubleshooting
255
