Action Yes No
Step 3
Remove the paper fragments and partially fed paper.
Does the problem remain?
Go to step 4. The problem is
solved.
Step 4
Clear the optional bin paper path rollers of any dirt and
contamination.
Does the problem remain?
Go to step 5. The problem is
solved.
Step 5
a Enter the Diagnostics menu, and then navigate to:
Output bin quick feed > Feed to all bins
b To uc h Single or Continuous.
Does the problem remain?
Go to step 6. The problem is
solved.
Step 6
a Enter the Diagnostics menu, and then navigate to:
Output device adjustments > Staple test
b Select the staple job for the right staple unit.
Does the finisher staple?
Go to step 13. Go to step 7.
Step 7
a Remove the SHPF left cover. See “Staple, hole punch finisher
left cover removal” on page 699.
b Make sure that the SHPF staple cartridge door close limit switch
is properly installed. Reseat the cable on the SHPF controller
board.
Does the problem remain?
Go to step 8. The problem is
solved.
Step 8
Check the limit switch and its connector pins for damage.
Are the limit switch and its connectors free of damage?
Go to step 10. Go to step 9.
Step 9
Replace the limit switch. See
“SHPF staple cartridge door close
limit switch removal” on page 706.
Does the problem remain?
Go to step 10. The problem is
solved.
4064
Diagnostics and troubleshooting
261
