Action Yes No
Step 10
a Remove the SHPF right cover. See “Staple, hole punch finisher
right cover removal” on page 701.
b Make sure that the staple cartridge is properly installed.
c Clear the staple unit of any obstructions.
d Reseat the staple unit cables.
Does the problem remain?
Go to step 11. The problem is
solved.
Step 11
Check the staple unit for damage.
Is the staple unit free of damage?
Go to step 13. Go to step 12.
Step 12
Replace the staple unit. See
“Right staple unit removal” on
page 726.
Does the problem remain?
Go to step 13. The problem is
solved.
Step 13
Make sure that the controller board of the aected optional bin is
properly installed. Reseat all the cables on the controller board.
Does the problem remain?
Go to step 14. The problem is
solved.
Step 14
Check the aected controller board and its connector pins for
damage.
Are the bin controller board and its connectors free of damage?
Contact the next
level of support.
Go to step 15.
Step 15
Replace the bin controller board. See
“Staple, hole punch finisher
controller board removal” on page 705.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
4064
Diagnostics and troubleshooting
