6.69. Sound Input Configuration Window
To go to the Sound Input Configuration Window, press Tools and tap at Sound Input .
This window displays the received sound wave from the connected audio-in.
To adjust the incoming sound signal into a curve that fits in the screen and does not overload, use the sound in
slider.
To adjust the BPM (Beats Per Minute) manually, use the BPM slider.
To leave the Sound Input Configuration Window, tap in the title bar or press Esc on the console.
Encoder Bar Functions
The default encoder speed is without decimal place.
To change the encoder speed to slow, press the encoder key . The encoder speed is with decimal place.
To change the encoder speed to ultra slow, press and hold the key and press the encoder key . The
encoder speed equals one DMX step.
Sound In(%):
To select the value of Sound In, turn the encoder left or right.
To open the calculator, press the encoder.
BPM:
To select the BPM, turn the encoder left or right.
