6.80. Wing Setup Window
To open the Wing Setup Window, tap at dot2 Wings in the Setup, and then tap at the three dots ... in the title
bar.
The Wing Setup Window is useful if technical support is needed.
The Wing Setup is a view only window to see the connection status of the console, wing or Node4.
To select a type, tap in the table. The row of a selected type has a blue background.
To leave the Wing Setup Window, tap in the title bar or press Esc on the console.
Type:
Displays the type.
IP Address:
Displays the IPv6 address.
Status:
Displays the connections status e.g. connected, not connected or downloading firmware.
Connections:
Displays the amount of connections.
Details Area
The details area displays details regarding the selected type.
Encoder Bar Functions
To Next Page
