Free:
This slot is free. You can assign a wing.
A free slot is displayed with a yellow status bar indicator.
Connected:
This slot is connected to an external wing.
Additional is the IPv6 address of the wing displayed.
A connected slot is displayed with a lime status bar indicator.
Assigned:
This slot is assigned to an external wing but NOT connected.
Additional is the IPv6 address of the wing displayed.
A assigned slot is displayed with a green status bar indicator.
Encoder Bar Functions
Wing:
To scroll in the wing slots column up or down, turn the encoder left or right.
To open the configure slot window, press or tap the encoder.
Related Links
Setup
Configure Slot Window
Wing Setup
