214683 149 Revision A
Figure 3.206: Case Combine Control Handle
10. To enable the presets, activate AHHC button (A) to
place the header on the ground. To enable the first
present, tap the button once. To enable the second
preset, tap the button twice.
To lift the header to maximum working height, hold the
SHIFT button on the back of the control handle while
tapping AHHC button (A).
Figure 3.207: Case Combine Display – Header
Setup Page
11. The maximum working height can be adjusted on the
HEADER SETUP page on the combine display. Enter
the desired height in the MAXIMUM WORKING
HEIGHT field (A).
Figure 3.208: Case Combine Console
12. If you need to change the position of one of the presets,
you can fine-tune this setting with button (A) on the
combine console.
OPERATION
