214683 482 Revision A
5.13 Float Module Stripper Bars and Feed Deflectors
5.13.1 Removing Stripper Bars
Figure 5.178: Stripper Bar
1. Detach the header from the combine. Refer to 4 Header
Attachment/Detachment, page 307.
2. Remove the four bolts and nuts (A) securing the
stripper bar (B) to the float module frame, and remove
the stripper bar.
3. Repeat at the opposite side.
MAINTENANCE AND SERVICING
