214683 553 Revision A
6.4.3 Secondary Stabilizer Wheel
Figure 6.14: Secondary Stabilizer Wheel
The secondary stabilizer wheel is added to existing
stabilizer wheels to help stabilize the header in field
conditions that would otherwise cause the header to bounce
and result in uneven cutting height. Installation and
adjustment instructions are included with the kit.
Available as an attachment for use with 9.1 m, 10.7 m,
12.2 m, and 13.7 m (30 ft., 35 ft., 40 ft., and 45 ft.) headers.
MD #B6179
56
6.4.4 Stabilizer Wheels and Slow Speed Transport Package
Stabilizer / slow speed transport wheels help to stabilize the header in field conditions that would otherwise cause
the header to bounce, resulting in uneven cutting heights. This system is similar to the Stabilizer Wheel option.
Refer to 6.4.2 Stabilizer Wheels, page 552.
Stabilizer / slow speed transport wheels are used to convert the header into transport mode for slow-speed towing
behind a properly-configured combine (or agricultural tractor). A tow pole and installation instructions are included
in the kit.
MD #C2007
OPTIONS AND ATTACHMENTS
56. Kit consists of one wheel assembly; two kits are required to upgrade both sides of the header.
