214683 549 Revision A
6.3 Cutterbar
6.3.1 Cutterbar Wearplate
Figure 6.7: Cutterbar Wearplates
Cutterbar wearplates are recommended for cutting on the
ground when the soil is adhering to the steel.
Order one of the following bundles based on header size:
• 13.7 m (45 ft.) – MD #B5114
6.3.2 Knifehead Shield
Figure 6.8: Knifehead Shield
Knifehead shields attach to the endsheets and reduce the
knifehead opening to prevent cut crop, particularly severely
lodged crop, from accumulating over the knifehead and
damaging the knife drive box and endsheet.
Order the following bundles according to
• Regular guards – MD #220101
• Stub guards – MD #220103
OPTIONS AND ATTACHMENTS
