MacDon FlexDraper FD140 - Component Identification; FD1 Series Flexdraper

214683 25 Revision A
2.3 Component Identification
2.3.1 FD1 Series FlexDraper
®®
Figure 2.2: FD1 Series FlexDraper
®®
Components
1017159
A
B
C
D
E
F
G
H
K
L
J
M
A - Wing Float Linkage B - Center Reel Arm C - Reel Fore-Aft Cylinder
D - Endshield E - Reel Lift Cylinder F - Knife Drive Box (inside endshield)
G - Side Draper H - Center Reel Drive J - Pick-up Reel
K - Reel Endshield L - Crop Divider M - Header Light (except Europe)
PRODUCT OVERVIEW
