214683 24 Revision A
Table 2.2 Header Attachments (continued)
Driveline overall length
2
Challenger, Gleaner,
John Deere, CLAAS,
Massey Ferguson
Maximum
(extended)
1.262 m
(49-11/16 in.)
O
F
Driveline overall length
2
Challenger, Gleaner,
John Deere, CLAAS,
Massey Ferguson
Minimum
(compressed)
916 mm
(36-1/16 in.)
O
F
Driveline overall length
2
John Deere 9650/9660
Maximum
(extended)
775 mm (30-1/2 in.) O
F
Driveline overall length
2
John Deere 9650/9660
Minimum
(compressed)
880 mm (34-5/8 in.) O
F
Upper Cross Auger O
D
Outside diameter 305 mm (12 in.)
—
Tube diameter
152 mm (6 in.)
—
Stabilizer Wheel / Slow Speed Transport O
D
Wheels 15 in.
—
Tires
P205/75 R-15
—
Weight
Estimated weight range – base header, no float module – variances are due to different package configurations.
9.1 m (30 ft.) header
2218–2317 kg (4890–5240 lb.)
10.7 m (35 ft.) header
2409–2558 kg (5310–5640 lb.)
12.2 m (40 ft.) header
North America frame
2644–2708 kg (5830–5970 lb.)
12.2 m (40 ft.) header Export frame
2685–2706 kg (5920–5965 lb.)
13.7 m (45 ft.) header
North America frame
2903 kg (6400 lb.)
13.7 m (45 ft.) header Export frame
2892–2912 kg (6375–6420 lb.)
PRODUCT OVERVIEW
