214683 284 Revision A
Configuring Reel Fore-Aft, Header Tilt, and Header Type (New Holland CR Series)
This procedure applies only to 2016 New Holland CR models 6.90, 7.90, 8.90, and 9.90.
NOTE:
Changes may have been made to the combine controls or display since this document was published. Refer to the
combine operator’s manual for updates.
Figure 3.507: New Holland Combine Controls
1. Simultaneously press the UNLOAD (A) and
RESUME (B) buttons on the control handle.
Figure 3.508: New Holland Combine Display
2. On the HEAD 1 screen, change the CUTTING TYPE
from FLEX to PLATFORM as shown at location (A).
OPERATION
