214683 371 Revision A
4.7.3 CR Feeder Deflectors
For New Holland combines only: Short feeder deflectors have been factory-installed on the float module to
improve feeding into the feeder house. Remove the feeder deflectors if necessary. Refer to 5.13.3 Replacing Feed
Deflectors on New Holland CR Combines, page 483.
Long feeder kits are provided for narrow feeder house combines and can be installed to replace the short
feeder deflectors.
Feeder House Size Feeder Kit Size MacDon Part Number
1250–1350 mm (49– 65 in.) Short: 200 mm (7-7/8 in.) MD #213613, 213614
1100 mm (43-1/2 in.) and below Long: 325 mm (12-13/16 in.) MD #213592, 213593
HEADER ATTACHMENT/DETACHMENT
