MacDon FlexDraper FD140 - FM100 Float Module

214683 26 Revision A
2.3.2 FM100 Float Module
Figure 2.3: Header Side of FM100 Float Module
1012484
A
B
C
D
E
F
F
B
G
H
A - Feed Auger B - Header Float Springs C - Center-Link
D - Hydraulic Reservoir E - Gearbox F - Header Support Arms
G - Feed Draper H - Hydraulic Filter
PRODUCT OVERVIEW
